895-050 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 50POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Card Type | Contact Type | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Color | Number of Rows [custom] | Number of Positions/Bay/Row | Gender | Pitch | Pitch | Termination | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Card Thickness [Max] | Card Thickness [Min] | Read Out | Contact Finish | Termination Rows | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Cantilever | Through Hole | 0.25 Ám | 10 Áin | Black | 2 | 25 | Female | 0.1 " | 2.54 mm | Solder | Copper Alloy | 125 °C | -40 C | 50 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Gold | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Cantilever | Right Angle Through Hole | 0.25 Ám | 10 Áin | Black | 2 | 25 | Female | 0.1 " | 2.54 mm | Solder | Copper Alloy | 125 °C | -40 C | 50 | Floating Bobbin Top Mount Opening | 2.95 mm | 0.116 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Gold | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | Cantilever | Right Angle Through Hole | 0.25 Ám | 10 Áin | Black | 50 | Female | 0.1 " | 2.54 mm | Solder | Copper Alloy | 125 °C | -40 C | 50 | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Gold | 1 | 1 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | Cantilever | Through Hole | 0.25 Ám | 10 Áin | Black | 50 | Female | 0.1 " | 2.54 mm | Wire Wrap | Copper Alloy | 125 °C | -40 C | 50 | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Gold | 1 | 1 | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Cantilever | Through Hole | 0.25 Ám | 10 Áin | Black | 2 | 25 | Female | 0.1 " | 2.54 mm | Wire Wrap | Copper Alloy | 125 °C | -40 C | 50 | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Gold | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Cantilever | Through Hole | 0.25 Ám | 10 Áin | Black | 2 | 25 | Female | 0.1 " | 2.54 mm | Solder | Copper Alloy | 125 °C | -40 C | 50 | Side Mount Opening Unthreaded | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Gold | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Cantilever | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | Black | 2 | 25 | Female | 0.1 " | 2.54 mm | Solder | Copper Alloy | 125 °C | -40 C | 50 | M3 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Gold | Card Extender | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Cantilever | Through Hole | 0.25 Ám | 10 Áin | Black | 2 | 25 | Female | 0.1 " | 2.54 mm | Solder | Copper Alloy | 125 °C | -40 C | 50 | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Gold | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Non Specified - Single Edge | Cantilever | Through Hole | 0.25 Ám | 10 Áin | Black | 50 | Female | 0.1 " | 2.54 mm | Solder | Copper Alloy | 125 °C | -40 C | 50 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Gold | 1 | 1 | ||||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Cantilever | Through Hole | 0.25 Ám | 10 Áin | Black | 2 | 25 | Female | 0.1 " | 2.54 mm | Solder | Copper Alloy | 125 °C | -40 C | 50 | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Gold |
