SMS24R Series

Manufacturer: Amphenol Aerospace Operations

Catalog

CONN RCPT HSG 24POS 5.08MM

Part	Note	Color	Contact Type	Number of Rows	Operating Temperature (Min)	Operating Temperature (Max)	Contact Termination	Row Spacing	Connector Type	Number of Positions	Pitch	Fastening Type	Insulation Material	Mounting Type	Features	Contact Material	Contact Shape	Contact Finish Thickness - Post	Contact Finish Thickness - Post (string_set)	Row Spacing - Mating	Insulation Color	Ingress Protection	Number of Positions Loaded	Contact Finish - Mating	Material Flammability Rating	Current Rating	Style	Contact Finish Thickness - Mating	Termination	Contact Length - Post	Pitch - Mating	Insulation Height	Contact Finish - Post	Contact Length - Mating	Overall Contact Length	Shrouding
Amphenol Aerospace Operations SMS24R3S6	Contacts Not Included	Gray	Female Male Male or Female	6	-40 °C	105 °C	Crimp	0.2 in	Receptacle	24 pos	5.08 mm	Latch Holder	Nylon 6/6 Polyamide (PA66)	Panel Mount Snap-In
Amphenol Aerospace Operations SMS24R3TR29	Contacts Not Included	Gray	Female Male Male or Female	6	-40 °C	105 °C	Crimp	0.2 in	Receptacle	24 pos	5.08 mm	Latch Holder	Nylon 6/6 Polyamide (PA66)	Panel Mount Snap-In
Amphenol Aerospace Operations SMS24RDH1	Contacts Not Included		Female Male Male or Female	4	-40 °C	105 °C	Crimp	0.2 in	Receptacle	24 pos	5.08 mm	Locking Ramp	Nylon 6/6 Polyamide (PA66)	Free Hanging (In-Line)	Strain Relief
Amphenol Aerospace Operations SMS24R-4TR29	Contacts Not Included	Gray			-40 °C	105 °C			Receptacle	24 pos			Nylon 6/6 Polyamide (PA66)		Flame Retardant
Amphenol Aerospace Operations SMS24RE3S6			Female Socket	6	-55 °C	105 °C			Receptacle	24 pos		Locking Ramp	Glass Filled Thermoplastic	Through Hole	Mounting Flange	Copper Alloy	Circular	Flash	Flash	0.2 in	Black	IP40	All	Gold	UL94 V-0	5 A	Board Board or Cable	29.5 Ąin	Solder	0.173 in	0.2 in	0.528 in	Gold
Amphenol Aerospace Operations SMS24RE4S6			Male Pin	6	-55 °C	125 °C			Header	24 pos		Locking Ramp	Glass Filled Polyester	Through Hole	Mounting Flange	Copper Alloy	Circular			0.2 in	Black	IP40	All	Gold	UL94 V-0	5 A	Board Cable/Wire	16 µin	Solder	0.173 in	0.2 in	0.52 in	Tin	0.28 in	0.972 in	Unshrouded
