857-013 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 26POS 0.156
| Part | Material - Insulation | Termination Rows | Gender | Pitch | Pitch | Mounting Type | Number of Rows [custom] | Color | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Contact Material | Number of Positions/Bay/Row | Card Type | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Read Out | Termination | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | 3.96 mm | 0.156 in | Through Hole | 2 | Black | 125 °C | -40 C | Gold | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 13 | Non Specified - Dual Edge | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 0.25 Ám | 10 Áin | 26 | Dual | Solder Eyelet(s) | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | 3.96 mm | 0.156 in | Through Hole | 2 | Black | 125 °C | -40 C | Gold | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 13 | Non Specified - Dual Edge | Flush Mount M3 Threaded Insert Top Opening | 0.25 Ám | 10 Áin | 26 | Dual | Solder Eyelet(s) | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | 3.96 mm | 0.156 in | Through Hole | 2 | Black | 125 °C | -40 C | Gold | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 13 | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | 26 | Dual | Solder Eyelet(s) | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | 3.96 mm | 0.156 in | Through Hole | 2 | Black | 125 °C | -40 C | Tin | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 13 | Non Specified - Dual Edge | 4-40 Flush Mount Threaded Insert Top Opening | 26 | Dual | Solder Eyelet(s) | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | 3.96 mm | 0.156 in | Right Angle Through Hole | Black | 125 °C | -40 C | Gold | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 13 | Non Specified - Single Edge | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | 13 | Single | Solder | 1 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | 3.96 mm | 0.156 in | Right Angle Through Hole | Black | 125 °C | -40 C | Gold | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 13 | Non Specified - Single Edge | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 0.25 Ám | 10 Áin | 13 | Single | Solder | 1 | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | 3.96 mm | 0.156 in | Right Angle Through Hole | Black | 125 °C | -40 C | Tin | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 13 | Non Specified - Single Edge | 13 | Single | Solder | 1 | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | 3.96 mm | 0.156 in | Through Hole | Black | 125 °C | -40 C | Gold | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 13 | Non Specified - Single Edge | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | 13 | Single | Wire Wrap | 1 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | 3.96 mm | 0.156 in | Through Hole | 2 | Black | 125 °C | -40 C | Gold | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 13 | Non Specified - Dual Edge | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 0.25 Ám | 10 Áin | 26 | Dual | Solder | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | 3.96 mm | 0.156 in | Through Hole | Black | 125 °C | -40 C | Gold | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 13 | Non Specified - Single Edge | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 0.25 Ám | 10 Áin | 13 | Single | Solder Eyelet(s) | 1 |
