DCWN06 Series

Catalog

DC DC CONVERTER +/-12V 6W

Part	Operating Temperature [Max]	Operating Temperature [Min]	Power (Watts)	Voltage - Input (Min) [Min]	Package / Case	Mounting Type	Applications	Number of Outputs	Current - Output (Max)	Voltage - Isolation	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Type	Voltage - Output 1	Efficiency	Voltage - Output 2	Voltage - Input (Max) [Max]	Features
MEAN WELL USA Inc. DCWN06B-12	90 °C	-40 °C	6 W	18 V	24-DIP Module 8 Leads	Through Hole	ITE (Commercial)	2	250 mA	3000 V	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in	Isolated Module	12 V	86 %	-12 V	36 V	OCP SCP UVLO
MEAN WELL USA Inc. DCWN06C-15	90 °C	-40 °C	6 W	36 V	24-DIP Module 8 Leads	Through Hole	ITE (Commercial)	2		3000 V	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in	Isolated Module	15 V	87 %	-15 V	72 V	OCP SCP UVLO
MEAN WELL USA Inc. DCWN06A-12	90 °C	-40 °C	6 W	9 V	24-DIP Module 8 Leads	Through Hole	ITE (Commercial)	2	250 mA	3000 V	0.8 "	0.4 "	31.8 mm	10.2 mm	20.3 mm	1.25 in	Isolated Module	12 V	83 %	-12 V	18 V	OCP SCP UVLO
