R-78T Series

Catalog

NON-ISOLATED DC/DC CONVERTERS 8-42VIN 5V 1A SIP3 23X27.2X10MM

Part	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Input (Min) [Min]	Power (Watts)	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Number of Outputs	Mounting Type	Voltage - Input (Max) [Max]	Voltage - Output 1	Current - Output (Max) [Max]	Efficiency	Features	Type	Applications	Package / Case
Recom Power R-78T5.0-1.0/AL-TRAY	85 °C	-40 C	8 V	5 W	0.91 in	0.39 "	23 mm	10 mm	0.98 "	25 mm	1	Surface Mount	42 V	5 V	1 A	92 %	SCP	Non-Isolated PoL Module	ITE (Commercial)
Recom Power R-78T12-1.0/AC-R	85 °C	-40 C	15 V	12 W	0.91 in	0.39 "	23 mm	10 mm	0.98 "	25 mm	1	Surface Mount	42 V	12 V	1 A	95 %	SCP	Non-Isolated PoL Module	ITE (Commercial)	3-SMD Module
Recom Power R-78T3.3-1.0/FC-TRAY	85 °C	-40 C	7 V	3 W	0.91 in	0.39 "	23 mm	10 mm	0.98 "	25 mm	1	Surface Mount	42 V	3.3 V	1 A	88 %	SCP	Non-Isolated PoL Module	ITE (Commercial)
Recom Power R-78T5.0-1.0/AC-R	85 °C	-40 C	8 V	5 W	0.91 in	0.39 "	23 mm	10 mm	0.98 "	25 mm	1	Surface Mount	42 V	5 V	1 A	92 %	SCP	Non-Isolated PoL Module	ITE (Commercial)	3-SMD Module
Recom Power R-78T12-1.0/AL-R	85 °C	-40 C	15 V	12 W	0.91 in	0.39 "	23 mm	10 mm	0.98 "	25 mm	1	Surface Mount	42 V	12 V	1 A	95 %	SCP	Non-Isolated PoL Module	ITE (Commercial)
Recom Power R-78T3.3-1.0/AC-R	85 °C	-40 C	7 V	3 W	0.91 in	0.39 "	23 mm	10 mm	0.98 "	25 mm	1	Surface Mount	42 V	3.3 V	1 A	88 %	SCP	Non-Isolated PoL Module	ITE (Commercial)	3-SMD Module
Recom Power R-78T3.3-1.0/AL-TRAY	85 °C	-40 C	7 V	3 W	0.91 in	0.39 "	23 mm	10 mm	0.98 "	25 mm	1	Surface Mount	42 V	3.3 V	1 A	88 %	SCP	Non-Isolated PoL Module	ITE (Commercial)
Recom Power R-78T5.0-1.0/FC-TRAY	85 °C	-40 C	8 V	5 W	0.91 in	0.39 "	23 mm	10 mm	0.98 "	25 mm	1	Surface Mount	42 V	5 V	1 A	92 %	SCP	Non-Isolated PoL Module	ITE (Commercial)
Recom Power R-78T3.3-1.0/AL-R	85 °C	-40 C	7 V	3 W	0.91 in	0.39 "	23 mm	10 mm	0.98 "	25 mm	1	Surface Mount	42 V	3.3 V	1 A	88 %	SCP	Non-Isolated PoL Module	ITE (Commercial)
Recom Power R-78T5.0-1.0/FC-R	85 °C	-40 C	8 V	5 W	0.91 in	0.39 "	23 mm	10 mm	0.98 "	25 mm	1	Surface Mount	42 V	5 V	1 A	92 %	SCP	Non-Isolated PoL Module	ITE (Commercial)
