YXS Series

Manufacturer: Rubycon

Catalog

ALUMINUM ELECTROLYTIC CAPACITORS - RADIAL LEADED LOW IMPEDANCE ELECTROLYTIC CAPACITORS

Part	Capacitance	Tolerance	Operating Temperature [Min]	Operating Temperature [Max]	Applications	Voltage - Rated	Polarization	Lead Spacing	Lead Spacing	Mounting Type	Lifetime @ Temp.	Size / Dimension [diameter]	Size / Dimension [diameter]	Ripple Current @ High Frequency	Package / Case	Ripple Current @ Low Frequency	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Impedance	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max] [z]
Rubycon 6.3YXS4700MEFC12.5X25	4700 µF	20 %	-40 C	105 ░C	General Purpose	6.3 VDC	Polar	0.197 "	5 mm	Through Hole	6000 Hrs	0.492 in	12.5 mm	2.65 A	Can Radial	1.855 A	1.063 in	27 mm	24 mOhms
Rubycon 6.3YXS22000MEFC18X40	22000 µF	20 %	-40 C	105 ░C	General Purpose	6.3 VDC	Polar	0.295 in	7.5 mm	Through Hole	6000 Hrs	0.709 in	18 mm	4.55 A	Can Radial	3.185 A			12 mOhms	42 mm	1.654 in
Rubycon 6.3YXS330MEFC6.3X11	330 µF	20 %	-40 C	105 ░C	General Purpose	6.3 VDC	Polar	0.098 in	2.5 mm	Through Hole	4000 Hrs	0.248 "	6.3 mm	340 mA	Can Radial	187 mA		0.492 in	220 mOhms			12.5 mm
Rubycon 35YXS4700MEFC18X40	4700 µF	20 %	-40 C	105 ░C	General Purpose	35 V	Polar	0.295 in	7.5 mm	Through Hole	6000 Hrs	0.709 in	18 mm	4.55 A	Can Radial	3.185 A			12 mOhms	42 mm	1.654 in
Rubycon 25YXS330MEFC8X16	330 µF	20 %	-40 C	105 ░C	General Purpose	25 VDC	Polar	0.138 in	3.5 mm	Through Hole	5000 Hrs	0.315 in	8 mm	1.05 A	Can Radial	577.5 mA			69 mOhms	0.689 in			17.5 mm
Rubycon 25YXS220MEFC6.3X11	220 µF	20 %	-40 C	105 ░C	General Purpose	25 VDC	Polar	0.098 in	2.5 mm	Through Hole	4000 Hrs	0.248 "	6.3 mm	340 mA	Can Radial	170 mA		0.492 in	220 mOhms			12.5 mm
Rubycon 6.3YXS5600MEFC12.5X25	5.6 mF	20 %	-40 C	105 ░C	General Purpose	6.3 VDC	Polar	0.197 "	5 mm	Through Hole	6000 Hrs	0.492 in	12.5 mm	2.65 A	Can Radial	1.855 A	1.063 in	27 mm	24 mOhms
Rubycon 10YXS1500MEFC10X16	1.5 mF	20 %	-40 C	105 ░C	General Purpose	10 V	Polar	0.197 "	5 mm	Through Hole	6000 Hrs	0.394 in	10 mm	1.45 A	Can Radial	870 mA			46 mOhms	0.689 in			17.5 mm
Rubycon 6.3YXS220MEFC5X11	220 µF	20 %	-40 C	105 ░C	General Purpose	6.3 VDC	Polar	0.079 in	2 mm	Through Hole	3000 Hrs	0.197 in	5 mm	210 mA	Can Radial	105 mA		0.492 in	580 mOhms			12.5 mm
Rubycon 25YXS390MEFC8X16	390 µF	20 %	-40 C	105 ░C	General Purpose	25 VDC	Polar	0.138 in	3.5 mm	Through Hole	5000 Hrs	0.315 in	8 mm	1.05 A	Can Radial	577.5 mA			69 mOhms	0.689 in			17.5 mm
