SRP0612 Series
Manufacturer: Bourns Inc.
Beta
⌘K
POWER INDUCTORS - SMD IND,7.1X6.7X1.2MM,4.7UH+/-10%,3.9A,SHD,SMD
| Part | Inductance Frequency - Test | DC Resistance (DCR) | Current Rating (Amps) | Material - Core | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Shielding | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Operating Temperature [Max] | Operating Temperature [Min] | Current - Saturation (Isat) | Frequency - Self Resonant | Package / Case | Inductance | Q @ Freq | Tolerance | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | 100 kHz | 82 mOhm | 3.9 A | Metal | 1.2 mm | 0.047 " | Shielded | 0.264 " | 6.7 mm | 7.1 mm | 0.28 in | 125 °C | -40 C | 5 A | 15 MHz | Nonstandard | 4.7 ÁH | 32 | 10 % | Surface Mount |
