807-032 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE DUAL FMALE 64POS 0.156
...
| Part | Gender | Card Type | Contact Finish | Operating Temperature [Max] | Operating Temperature [Min] | Read Out | Number of Rows [custom] | Contact Type | Number of Positions | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Contact Material | Termination Rows | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Material - Insulation | Pitch | Pitch | Termination | Color | Number of Positions/Bay/Row | Mounting Type | Number of Rows | Termination Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Female | Non Specified - Dual Edge | Gold | 125 °C | -40 C | Dual | 2 | Semi Bellows | 64 | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Copper Alloy | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | Solder | Green | 32 | Through Hole | |||
 EDAC Inc. | Female | Non Specified - Single Edge | Tin | 125 °C | -40 C | Single | Semi Bellows | Copper Alloy | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | Solder | Green | 32 | Right Angle Through Hole | 1 | |||||||||
 EDAC Inc. | Female | Non Specified - Dual Edge | Gold | 125 °C | -40 C | Dual | 2 | Semi Bellows | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | Solder | Green | 16 | Through Hole | 2 | ||||
 EDAC Inc. | Female | Non Specified - Dual Edge | Tin | 125 °C | -40 C | Dual | 2 | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | Wire Wrap | Green | 16 | Through Hole | 2 | ||||||||
 EDAC Inc. | Female | Non Specified - Dual Edge | Gold | 125 °C | -40 C | Dual | 2 | Semi Bellows | 64 | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Copper Alloy | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | Wire Wrap | Green | 32 | Through Hole | |||
 EDAC Inc. | Female | Non Specified - Dual Edge | Tin | 125 °C | -40 C | Dual | 2 | Semi Bellows | 64 | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | Copper Alloy | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | Solder Eyelet(s) | Green | 32 | Through Hole | |||||
 EDAC Inc. | Female | Non Specified - Dual Edge | Gold | 125 °C | -40 C | Dual | 2 | Semi Bellows | Flush Mount M3 Threaded Insert Top Opening | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | Solder | Green | 16 | Board Edge Straddle Mount | 2 | Card Extender | |||||
 EDAC Inc. | Female | Non Specified - Dual Edge | Gold | 125 °C | -40 C | Dual | 2 | Semi Bellows | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | Wire Wrap | Green | 16 | Through Hole | 2 | ||||
 EDAC Inc. | Female | Non Specified - Single Edge | Tin | 125 °C | -40 C | Single | Semi Bellows | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Copper Alloy | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | Solder | Green | 32 | Through Hole | 1 | ||||||
 EDAC Inc. | Female | Non Specified - Single Edge | Gold | 125 °C | -40 C | Single | Semi Bellows | 0.128 " | Side Mount Opening Unthreaded | 3.25 mm | Copper Alloy | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | Wire Wrap | Green | 32 | Through Hole | 1 |
