Liquid Level Sensors LLS
Liquid Level Sensors LLS
| Part | Switch Actuation Level | Switch Actuation Level | Material - Housing & Prism | Type | Operating Temperature [Max] | Operating Temperature [Min] | Output Type | Mounting Type | Minimum Liquid Specific Gravity [Min] | Current | Output Configuration | Voltage Rating | Switch Actuation Level |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sensata-Crydom | 1.181 in 2.953 in | 30 mm 75 mm | Polyphenylene Sulphide (PPS) | Liquid | 85 °C | -10 °C | Switch (2) (Single Float) | M16x2 Thread Panel Mount | 0.85 | 600 mA | SPST-NC/NO | 120 VDC 240 VAC | |
 Sensata-Crydom | 1.969 in 5.906 " 50 mm 150 mm | Polyphenylene Sulphide (PPS) | Liquid | 85 °C | -10 °C | Switch (2) (Dual Float) | M16x2 Thread Panel Mount | 0.85 | 600 mA | SPST-NC/NO | 120 VDC 240 VAC | ||
 Sensata-Crydom | 50 mm 100 mm | 1.969 in 3.937 in | Polyphenylene Sulphide (PPS) | Liquid | 85 °C | -10 °C | Switch (2) (Dual Float) | M16x2 Thread Panel Mount | 0.85 | 600 mA | SPST-NC/NO | 120 VDC 240 VAC | |
 Sensata-Crydom | 1.181 in 5.906 in | 30 mm | Polyphenylene Sulphide (PPS) | Liquid | 85 °C | -10 °C | Switch (2) (Single Float) | M16x2 Thread Panel Mount | 0.85 | 600 mA | SPST-NC/NO | 120 VDC 240 VAC | 150 mm |
 Sensata-Crydom | 30 mm 100 mm | 1.181 " 3.937 in | Polyphenylene Sulphide (PPS) | Liquid | 85 °C | -10 °C | Switch (2) (Single Float) | M16x2 Thread Panel Mount | 0.85 | 600 mA | SPST-NC/NO | 120 VDC 240 VAC | |
 Sensata-Crydom | 1.181 " 6.89 in 30 mm 175 mm | Polyphenylene Sulphide (PPS) | Liquid | 85 °C | -10 °C | Switch (2) (Single Float) | M16x2 Thread Panel Mount | 0.85 | 600 mA | SPST-NC/NO | 120 VDC 240 VAC | ||
 Sensata-Crydom | 1.969 in 5.906 " 50 mm 150 mm | Polyphenylene Sulphide (PPS) | Liquid | 85 °C | -10 °C | Switch (2) (Dual Float) | M16x2 Thread Panel Mount | 0.85 | 600 mA | SPST-NC/NO | 120 VDC 240 VAC | ||
 Sensata-Crydom | 50 mm 100 mm | 1.969 in 3.937 in | Polyphenylene Sulphide (PPS) | Liquid | 85 °C | -10 °C | Switch (2) (Dual Float) | M16x2 Thread Panel Mount | 0.85 | 600 mA | SPST-NC/NO | 120 VDC 240 VAC | |
 Sensata-Crydom | 1.181 in 4.921 in | 30 mm 125 mm | Polyphenylene Sulphide (PPS) | Liquid | 85 °C | -10 °C | Switch (2) (Single Float) | M16x2 Thread Panel Mount | 0.85 | 600 mA | SPST-NC/NO | 120 VDC 240 VAC |
