Bipolar Module - Thyristor E2-Pack
Description
AI
The Dual Thyristor Modules Portfolio offers various packages and breakdown voltages up to 2200V.
Beta
⌘K
Bipolar Module - Thyristor E2-Pack
Bipolar Module - Thyristor E2-Pack
| Part | Current - On State (It (RMS)) (Max) [Max] | Mounting Type | Voltage - Off State | Current - Gate Trigger (Igt) (Max) [Max] | Structure | Current - Non Rep. Surge 50, 60Hz (Itsm) | Operating Temperature [Min] | Operating Temperature [Max] | Package / Case | Current - Hold (Ih) (Max) [Max] | Number of SCRs, Diodes | Current - On State (It (AV)) (Max) [Max] | Voltage - Gate Trigger (Vgt) (Max) | Number of SCRs, Diodes [custom] | Number of SCRs, Diodes [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
LITTELFUSE | 190 A | Chassis Mount | 2.2 kV | 100 mA | Series Connection - All SCRs | 2200 A 2380 A | -40 °C | 140 °C | TO-240AA | 150 mA | 2 SCRs | 120 A | 1.5 V | ||
 LITTELFUSE | Chassis Mount | 2.2 kV | 70 mA | Bridge 3-Phase - SCRs/Diodes - IGBT with Diode | 500 A 540 A | -40 °C | 150 °C | E2 | 100 mA | 1.4 V | 3 | 3 |
