PPPC151 Series

Catalog

CONN HDR 15POS 0.1 GOLD PCB R/A

Part	Insulation Material	Contact Finish Thickness - Post	Contact Shape	Contact Material	Connector Type	Termination	Contact Finish Thickness - Mating	Operating Temperature [Min]	Operating Temperature [Max]	Current Rating (Amps)	Number of Rows	Material Flammability Rating	Number of Positions	Contact Finish - Post	Mounting Type	Voltage Rating	Insulation Height	Insulation Height	Fastening Type	Pitch - Mating	Pitch - Mating	Contact Type	Contact Length - Post	Contact Length - Post	Number of Positions Loaded	Insulation Color	Contact Finish - Mating
Sullins Connector Solutions PPPC151LGBN	Polyester	Flash	Square	Phosphor Bronze	Header	Solder	Flash	-40 C	105 ░C	3 A	1	UL94 V-0	15	Gold	Right Angle Through Hole	250 V	0.1 in	2.54 mm	Push-Pull	0.1 "	2.54 mm	Female Socket	0.124 in	3.15 mm	All	Black	Gold
