AWHW 06 Series
Manufacturer: Assmann WSW Components
Beta
⌘K
DIN 41651 HEADER MALE THT 6PIN
| Part | Number of Rows [custom] | Insulation Height [z] | Insulation Height [z] | Fastening Type | Contact Length - Mating | Contact Length - Mating | Operating Temperature [Min] | Operating Temperature [Max] | Shrouding | Insulation Color | Style | Contact Finish - Post | Number of Positions Loaded | Contact Shape | Contact Type | Mounting Type | Contact Length - Post | Contact Length - Post | Material Flammability Rating | Row Spacing - Mating [x] | Row Spacing - Mating [x] | Termination | Connector Type | Number of Positions | Contact Material | Current Rating (Amps) | Insulation Material | Features | Pitch - Mating | Pitch - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Assmann WSW Components | 2 | 0.352 in | 8.95 mm | Push-Pull | 0.224 in | 5.7 mm | -40 C | 105 ░C | Shrouded - 4 Wall | Gray | Board to Cable/Wire | Tin | All | Square | Male Pin | Right Angle Through Hole | 0.124 in | 3.15 mm | UL94 V-0 | 0.1 in | 2.54 mm | Solder | Header | 6 | Brass | 3 A | Polybutylene Terephthalate (PBT) Glass Filled | Keying Slot | 0.1 " | 2.54 mm |
