6791222 Series
Manufacturer: DIALIGHT
Beta
⌘K
LED PANEL INDCATOR GREEN 6V
| Part | Lens Style | Ingress Protection | Current | Type | Ratings | Millicandela Rating | Viewing Angle | Wavelength - Peak | Panel Cutout Dimensions | Panel Cutout Dimensions | Lamp Color | Lens Size [diameter] | Termination Style | Voltage | Panel Cutout Shape |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 DIALIGHT | Round with Domed Top | IP66 NEMA 4X | 30 mA | LED | DC | 25000 mcd | 30 ° | 525 nm | 0.37 in | 9.35 mm | Green | 6 mm | Solder Lug | 6 V | Round |
 DIALIGHT | Round with Domed Top | IP66 NEMA 4X | 30 mA | LED | DC | 5870 mcd | 0.37 in | 9.4 mm | Green | 6 mm | Solder Lug | 12 V | Round | ||
DIALIGHT | Round with Domed Top | IP66 NEMA 4X | 30 mA | LED | DC | 25000 mcd | 30 ° | 525 nm | 0.37 in | 9.35 mm | Green | 6 mm | Solder Lug | 24 V | Round |
