DE09 Series
Manufacturer: Adam Tech
Beta
⌘K
CONN D-SUB PIN 9 POS 1.38MM SOLDER ST THRU-HOLE 9 TERMINAL 1 PORT TRAY
| Part | Dielectric Material | Voltage Rating | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Color | Contact Finish Thickness | Contact Finish | Mounting Type | Connector Type | Number of Rows [custom] | Material Flammability Rating | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Termination | Number of Positions | Current Rating (Amps) | Connector Style | Flange Feature | Flange Feature | Features | Shell Material, Finish | Contact Form | Backset Spacing | Backset Spacing |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Adam Tech | Polybutylene Terephthalate (PBT) Glass Filled | 250 V | -65 ░C | 125 °C | Phosphor Bronze | Black | Flash | Gold | Through Hole | Plug Male Pins | 2 | UL94 V-0 | 1 | DE E | Solder | 9 | 5 A | D-Sub | Housing/Shell | 4-40 | Grounding Indents | ||||
 Adam Tech | Polybutylene Terephthalate (PBT) Glass Filled | 250 VAC | -65 ░C | 125 °C | Copper Alloy | Black | Flash | Gold | Through Hole | Plug Male Pins | 2 | UL94 V-0 | 1 | DE E | Solder | 9 | D-Sub | Housing/Shell (Unthreaded) | Grounding Indents | Steel | |||||
 Adam Tech | Polybutylene Terephthalate (PBT) Glass Filled | 250 VAC | -55 C | 105 ░C | Copper Alloy | Black | Gold | Right Angle Through Hole | Receptacle Female Sockets | 2 | UL94 V-0 | 1 | DE E | Solder | 9 | 3 A | D-Sub | 4-40 Mating Side Female Screwlock | Board Lock | Stamped | 0.319 in | 8.1 mm | |||
 Adam Tech | Polybutylene Terephthalate (PBT) Glass Filled | 250 VAC | -55 C | 105 ░C | Copper Alloy | Black | Flash | Gold | Free Hanging (In-Line) | Plug Male Pins | 2 | UL94 V-0 | 1 | DE E | 9 | 3 A | D-Sub | Cable Side (4-40) | Grounding Indents | Stamped | |||||
 Adam Tech | Free Hanging (In-Line) | Plug for Male Contacts | 2 | 1 | DE E | 9 | D-Sub | Cable Side (4-40) | Grounding Indents | ||||||||||||||||
 Adam Tech | Polybutylene Terephthalate (PBT) Glass Filled | 250 VAC | Copper Alloy | Black | Flash | Gold | Through Hole | Plug Male Pins | 2 | UL94 V-0 | 1 | DE E | Solder | 9 | 3 A | D-Sub | Board Side (4-40) | Board Lock Grounding Indents | |||||||
 Adam Tech | Polybutylene Terephthalate (PBT) Glass Filled | 250 VAC | Copper Alloy | Black | Gold | Free Hanging (In-Line) | Receptacle Female Sockets | 2 | UL94 V-0 | 1 | DE E | 9 | 5 A | D-Sub | Housing/Shell (Unthreaded) | ||||||||||
 Adam Tech | Polybutylene Terephthalate (PBT) Glass Filled | 250 VAC | -65 ░C | 125 °C | Phosphor Bronze | Black | Flash | Gold | Right Angle Through Hole | Receptacle Female Sockets | 2 | UL94 V-0 | 1 | DE E | Solder | 9 | 5 A | D-Sub | 4-40 Mating Side Female Screwlock | Board Lock | 0.197 in | 5 mm | |||
 Adam Tech | Polybutylene Terephthalate (PBT) Glass Filled | 250 VAC | -20 ░C | 85 °C | Copper Alloy | Black | Gold | Right Angle Through Hole | Receptacle Female Sockets | 2 | UL94 V-0 | 1 | DE E | Solder | 9 | 3 A | D-Sub | Housing/Shell | 4-40 | Board Lock | Stamped | 0.319 in | 8.1 mm | ||
 Adam Tech | Polybutylene Terephthalate (PBT) Glass Filled | 250 VAC | -65 ░C | 125 °C | Phosphor Bronze | Black | Flash | Gold | Through Hole | Receptacle Female Sockets | 2 | UL94 V-0 | 1 | DE E | Solder | 9 | 5 A | D-Sub | Housing/Shell (Unthreaded) |
