5100/50C Series
Manufacturer: ALPHA WIRE
Beta
⌘K
CABLE 50 COND 24AWG BLACK 1000'
| Part | Shield Material | Shield Coverage | Conductor Strand [custom] | Conductor Strand [custom] | Voltage | Length | Length | Jacket Color | Features | Jacket (Insulation) Diameter | Jacket (Insulation) Diameter | Usage | Conductor Material | Ratings | Operating Temperature [Min] | Operating Temperature [Max] | Shield Type | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Cable Type | Number of Conductors | Conductor Insulation | Jacket (Insulation) Material | Wire Gauge | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ALPHA WIRE | Aluminum | 100 % | 7 | 32 AWG | 300 VDC | 304.8 m | 1000 ft | Black | Biological Compatibility Drain Wire Rip Cord | 11 mm | 0.433 " | Communication Control | Copper Tinned | ISO 10993 | -35 °C | 105 ░C | Foil | 0.813 mm | 0.032 in | Multi-Conductor | 50 | Poly-Vinyl Chloride (PVC) | Poly-Vinyl Chloride (PVC) | 24 AWG | ||
 ALPHA WIRE | Aluminum | 100 % | 7 | 32 AWG | 300 VDC | Slate | Biological Compatibility Drain Wire Rip Cord | 11 mm | 0.433 " | Communication Control | Copper Tinned | ISO 10993 | -35 °C | 105 ░C | Foil | 0.813 mm | 0.032 in | Multi-Conductor | 50 | Poly-Vinyl Chloride (PVC) | Poly-Vinyl Chloride (PVC) | 24 AWG | 100 ft | 30.5 m |
