TR9CE7500 Series
Manufacturer: GlobTek, Inc.
Beta
⌘K
AC/DC DESKTOP ADAPTER 12V 90W
| Part | Efficiency | Input Connector | Input Type | Form | No Load Power Consumption | Region Utilized | Polarization | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Current - Output (Max) [Max] | Applications | Output Connector [diameter] | Output Connector [x] | Output Connector | Approval Agency | Cord Length | Cord Length | Voltage - Output | Operating Temperature [Max] | Operating Temperature [Min] | Power (Watts) | Voltage - Input [Max] | Voltage - Input [Min] | Standard Number |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 GlobTek, Inc. | CoC Tier 2 Level VI | IEC 320-C14 | Cord (Sold Separately) | Desktop (Class I) | 150 mW | International | Positive Center | 34 mm | 1.34 " | 5.88 " | 149.3 mm | 2.47 " | 62.8 mm | 7.5 A | Household Appliances ITE (Commercial) Medical | 2.5 mm 5.5 mm | 9.5 mm | Barrel Plug | CB CCC CE cETLus EAC ETL LPS PSE RCM S-Mark UkrSEPRO VCCI | 1.2 m | 47.2 in | 12 V | 50 °C | 0 °C | 90 W | 264 VAC | 90 VAC | |
 GlobTek, Inc. | CoC Tier 1 Level VI | IEC 320-C14 | Cord (Sold Separately) | Desktop (Class I) | 150 mW | International | Positive Center | 34 mm | 1.34 " | 5.88 " | 149.4 mm | 2.47 " | 62.8 mm | 7.5 A | Household Appliances ITE (Commercial) Medical | 2.5 mm 5.5 mm | 11 mm | Barrel Plug | CB CCC CE cETLus EAC ETL LPS PSE RCM S-Mark UkrSEPRO VCCI | 1.2 m | 47.2 in | 12 V | 40 °C | -10 °C | 90 W | 264 VAC | 90 VAC | 60335-1 60601-1 60950-1 62368-1 |
 GlobTek, Inc. | Level VI | IEC 320-C14 | Cord (Sold Separately) | Desktop (Class I) | 150 mW | International | Positive Center | 34 mm | 1.34 " | 5.88 " | 149.3 mm | 2.47 " | 62.8 mm | 7.5 A | Household Appliances ITE (Commercial) Medical | 2.5 mm 5.5 mm | 11 mm | Barrel Plug | CB CCC CE cETLus EAC ETL LPS PSE RCM S-Mark UkrSEPRO VCCI | 1.2 m | 47.2 in | 12 V | 50 °C | 0 °C | 90 W | 264 VAC | 90 VAC | 1310 60335-1 60601-1-11 60601-1-2 60950-1 61347-1 62368-1 |
 GlobTek, Inc. | CoC Tier 2 Level VI | IEC 320-C14 | Cord (Sold Separately) | Desktop (Class I) | 150 mW | International | 34 mm | 1.34 " | 5.88 " | 149.3 mm | 2.47 " | 62.8 mm | 7.5 A | Household Appliances ITE (Commercial) Medical | Power DIN 4 Pin | CB CCC CE cETLus EAC ETL LPS PSE RCM S-Mark UkrSEPRO VCCI | 1.2 m | 47.2 in | 12 V | 50 °C | 0 °C | 90 W | 264 VAC | 90 VAC | 1310 60335-1 60601-1-11 60601-1-2 60950-1 61347-1 62368-1 |
