MTA206 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
SWITCH TOGGLE SP3T 6A 125V
| Part | Actuator Material | Electrical Life | Circuit | Current Rating (Amps) | Mounting Type | Actuator Length [x] | Voltage Rating - DC | Switch Function | Termination Style | Bushing Thread | Operating Temperature [Max] | Operating Temperature [Min] | Panel Cutout Dimensions [diameter] | Actuator Type | Features | Voltage Rating - AC | Illumination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Copper Alloy Chrome Plated | 60000 Cycles | SP3T | 4 A 6 A | Panel Mount | 10.49 mm | 28 V | Mom-On-Mom | Solder Lug | 1/4-40 | 80 °C | -20 ░C | 6.4 mm | Standard Round | Jumper needed to achieve triple throw | 125 V | Non-Illuminated |
TE Connectivity AMP Connectors | Brass Nickel Plated | DPDT | 4 A 6 A | Panel Mount | 10.49 mm | 28 V | Mom-Off-Mom | PC Pin | 1/4-40 | 80 °C | -20 ░C | Standard Round | Epoxy Sealed Terminals | 125 V | Non-Illuminated | ||
TE Connectivity AMP Connectors | Copper Alloy Chrome Plated | 60000 Cycles | DPDT | 4 A 6 A | Panel Mount | 10.49 mm | 28 V | On-Off-Mom | PC Pin | 1/4-40 | 80 °C | -20 ░C | 6.4 mm | Standard Round | Epoxy Sealed Terminals | 125 V | Non-Illuminated |
 TE Connectivity AMP Connectors | Brass Nickel Plated | 80000 Cycles | DPDT | 4 A 6 A | Panel Mount | 10.49 mm | 28 V | On-On | Solder Lug | 1/4-40 | 80 °C | -20 ░C | 6.4 mm | Standard Round | Epoxy Sealed Terminals | 125 V | Non-Illuminated |
TE Connectivity AMP Connectors | Copper Alloy Chrome Plated | 60000 Cycles | DPDT | 4 A 6 A | Panel Mount | 10.49 mm | 28 V | On-Off-Mom | Solder Lug | 1/4-40 | 80 °C | -20 ░C | 6.4 mm | Standard Round | Epoxy Sealed Terminals | 125 V | Non-Illuminated |
TE Connectivity AMP Connectors | Brass Nickel Plated | DPDT | 4 A 6 A | Panel Mount | 10.49 mm | 28 V | On-Mom | PC Pin | 1/4-40 | 80 °C | -20 ░C | Standard Round | Epoxy Sealed Terminals | 125 V | Non-Illuminated | ||
TE Connectivity AMP Connectors | Brass Nickel Plated | DPDT | 4 A 6 A | Panel Mount | 10.49 mm | 28 V | On-Off-On | PC Pin | 1/4-40 | 80 °C | -20 ░C | Standard Round | Epoxy Sealed Terminals | 125 V | Non-Illuminated | ||
 TE Connectivity AMP Connectors | Copper Alloy Chrome Plated | 60000 Cycles | SP3T | 4 A 6 A | Panel Mount | 10.49 mm | 28 V | On-On-On | Solder Lug | 1/4-40 | 80 °C | -20 ░C | 6.4 mm | Standard Round | Jumper needed to achieve triple throw | 125 V | Non-Illuminated |
