3107A Series
Manufacturer: Belden Inc.
Beta
⌘K
MULTI-PAIR 4COND 22AWG BLK
| Part | Shield Material | Shield Coverage | Conductor Insulation | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Voltage | Conductor Strand [custom] | Conductor Strand [custom] | Conductor Material | Cable Type | Shield Type | Jacket Color | Features | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Wire Gauge | Jacket (Insulation) Material | Operating Temperature [Min] | Operating Temperature [Max] | Number of Conductors |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | Aluminum Copper Tinned | 65 % 100 % | Foam High Density Polyethylene (FHDPE) | 8.89 mm | 0.35 in | 300 VDC | 30 AWG | 7 | Copper Tinned | Multi-Pair | Braid Foil | Black | Drain Wire | 0.053 " | 1.346 mm | 22 AWG | Poly-Vinyl Chloride (PVC) | -20 ░C | 60 °C | 4 |
