73002W Series
Manufacturer: Belden Inc.
Beta
⌘K
CABLE 2COND 20AWG GRAY
| Part | Number of Conductors | Cable Type | Conductor Insulation | Features | Ratings | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Conductor Material | Jacket (Insulation) Material | Length | Length | Wire Gauge | Conductor Strand [custom] | Conductor Strand [custom] | Jacket Color | Voltage | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | 2 | Multi-Conductor | Poly-Vinyl Chloride (PVC) | Oil Resistant | UL Style 2587 | 0.238 " | 6.05 mm | Copper Bare | Poly-Vinyl Chloride (PVC) | 304.8 m | 1000 ft | 20 AWG | 10 | 30 AWG | Gray | 600 V | 0.035 in | 0.889 mm | ||
Belden Inc. | 2 | Multi-Conductor | Poly-Vinyl Chloride (PVC) | Oil Resistant | UL Style 2587 | 0.238 " | 6.05 mm | Copper Bare | Poly-Vinyl Chloride (PVC) | 20 AWG | 10 | 30 AWG | Gray | 600 V | 0.035 in | 0.889 mm | 100 ft | 30.5 m |
