SR11-5V Series
Manufacturer: Same Sky (Formerly CUI Devices)
Beta
⌘K
RELAY GENERAL PURPOSE DPDT 1A 5V
| Part | Coil Current | Load - Max Switching | Must Operate Voltage | Termination Style | Switching Voltage | Release Time | Contact Form | Coil Voltage | Relay Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Coil Type | Must Release Voltage | Mounting Type | Coil Resistance | Contact Rating (Current) | Operate Time |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Same Sky (Formerly CUI Devices) | 40 mA | 24 W 120 VA | 3.75 VDC | PC Pin | 24 VDC 120 VAC | 3 ms | DPDT (2 Form C) | 5 VDC | General Purpose | -25 °C | 70 °C | Gold (Au) Silver (Ag) | Non Latching | 0.5 VDC | Through Hole | 125 Ohms | 1 A | 7 ms |
Same Sky (Formerly CUI Devices) | 40 mA | 24 W 120 VA | 3.75 VDC | PC Pin | 24 VDC 120 VAC | 3 ms | DPDT (2 Form C) | 5 VDC | General Purpose | -25 °C | 70 °C | Gold (Au) Silver (Ag) | Non Latching | 0.5 VDC | Through Hole | 1 A | 7 ms |
