2338245 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

EP2.5 HDR 5P VERT BOSS,GREEN,UL

Part	Termination	Contact Length - Post [x]	Contact Length - Post [x]	Mounting Type	Contact Length - Mating	Contact Length - Mating	Contact Finish - Post	Fastening Type	Shrouding	Contact Shape	Connector Type	Insulation Height [z]	Insulation Height [z]	Material Flammability Rating	Style	Contact Type	Features	Number of Rows	Number of Positions Loaded	Contact Material	Insulation Material	Pitch - Mating	Pitch - Mating	Insulation Color	Voltage Rating	Current Rating (Amps)	Operating Temperature [Max]	Operating Temperature [Min]	Number of Positions
TE Connectivity Raychem Cable Protection 8-2338245-5	Kinked Pin Solder	0.134 in	3.4 mm	Through Hole	3.61 mm	0.142 in	Tin	Locking Ramp	Shrouded - 4 Wall	Circular	Header	0.346 in	8.8 mm	UL94 V-0	Board to Cable/Wire	Male Pin	Board Guide	1	All	Brass	Polybutylene Terephthalate (PBT)	2.5 mm	0.098 in	Green
TE Connectivity Raychem Cable Protection 8-2338245-8	Kinked Pin Solder	0.134 in	3.4 mm	Through Hole	3.6 mm	0.142 in	Tin	Locking Ramp	Shrouded - 4 Wall	Circular	Header	0.346 in	8.8 mm	UL94 V-0	Board to Cable/Wire	Male Pin	Board Guide	1	All	Brass	Polybutylene Terephthalate (PBT)	2.5 mm	0.098 in	Green	250 VAC	4.2 A	105 ░C	-55 °C	8
TE Connectivity Raychem Cable Protection 4-2338245-8	Kinked Pin Solder	0.134 in	3.4 mm	Through Hole	3.61 mm	0.142 in	Tin	Locking Ramp	Shrouded - 4 Wall	Circular	Header	0.346 in	8.8 mm	UL94 V-0	Board to Cable/Wire	Male Pin	Board Guide	1	All	Brass	Polybutylene Terephthalate (PBT)	2.5 mm	0.098 in	Black					8
TE Connectivity Raychem Cable Protection 6-2338245-4	Kinked Pin Solder	0.134 in	3.4 mm	Through Hole	3.61 mm	0.142 in	Tin	Locking Ramp	Shrouded - 4 Wall	Circular	Header	0.346 in	8.8 mm	UL94 V-0	Board to Cable/Wire	Male Pin	Board Guide	1	All	Brass	Polybutylene Terephthalate (PBT)	2.5 mm	0.098 in	Yellow					4
TE Connectivity Raychem Cable Protection 6-2338245-3	Kinked Pin Solder	0.134 in	3.4 mm	Through Hole	3.61 mm	0.142 in	Tin	Locking Ramp	Shrouded - 4 Wall	Circular	Header	0.346 in	8.8 mm	UL94 V-0	Board to Cable/Wire	Male Pin	Board Guide	1	All	Brass	Polybutylene Terephthalate (PBT)	2.5 mm	0.098 in	Yellow
