3659 Series

Catalog

CBL RIBN 25COND 0.05 BLACK 5'

Part	Conductor Material	Insulation Resistance	First Conductor Mark	Ribbon Width [custom]	Ribbon Width [custom]	Conductor Strand [custom]	Conductor Strand [custom]	Length	Length	Jacket Color	Features	Wire Gauge	Operating Temperature [Min]	Operating Temperature [Max]	Voltage	Shielding	Length [x]	Length [x]	Pitch	Pitch	Jacket (Insulation) Material	Cable Type	Number of Conductors [custom]	Ratings	Number of Conductors	Length	Number of Conductors [custom]
3M Electronic Specialty 3659/25 100SF	Copper Tinned	10 GOhm	Red	1.2 in	30.48 mm	36 AWG	7 Strands	3.05 m 7.62 m 30.48 m 304.8 mm	1 ft 10 ft 25 ft 100 '	Black	Splice Free Zippable	28 AWG	-20 ░C	105 ░C	300 VDC	Shielded	50 ft	15.24 m	0.05 in	1.27 mm	Poly-Vinyl Chloride (PVC)	Flat Cable Round Jacket	25	UL Style 20267
3M Electronic Specialty 3659/37 100SF	Copper Tinned	10 GOhm	Red	1.8 in	45.72 mm	36 AWG	7 Strands	3.05 m 7.62 m 30.48 m 304.8 mm	1 ft 10 ft 25 ft 100 '	Black	Splice Free Zippable	28 AWG	-20 ░C	105 ░C	300 VDC	Shielded	50 ft	15.24 m	0.05 in	1.27 mm	Poly-Vinyl Chloride (PVC)	Flat Cable Round Jacket		UL Style 20267	37
3M Electronic Specialty 3659/16 100	Copper Tinned	10 GOhm	Red	0.75 in	19.05 mm	36 AWG	7 Strands	3.05 m 7.62 m 30.48 m 304.8 mm	1 ft 10 ft 25 ft 100 '	Black	Zippable	28 AWG	-20 ░C	105 ░C	300 VDC	Shielded	50 ft	15.24 m	0.05 in	1.27 mm	Poly-Vinyl Chloride (PVC)	Flat Cable Round Jacket		UL Style 20267	16
3M Electronic Specialty 3659/34 100SF	Copper Tinned	10 GOhm	Red	1.65 in	41.91 mm	36 AWG	7 Strands	3.05 m 7.62 m 30.48 m 304.8 mm	1 ft 10 ft 25 ft 100 '	Black	Splice Free Zippable	28 AWG	-20 ░C	105 ░C	300 VDC	Shielded	50 ft	15.24 m	0.05 in	1.27 mm	Poly-Vinyl Chloride (PVC)	Flat Cable Round Jacket		UL Style 20267	34
3M Electronic Specialty 3659/37SF 300	Copper Tinned	10 GOhm	Red	1.8 in	45.72 mm	36 AWG	7 Strands	3.05 m 7.62 m 30.48 m 304.8 mm 91440 mm	1 ft 10 ft 25 ft 100 ' 3600 in	Black	Zippable	28 AWG	-20 ░C	105 ░C	300 VDC	Shielded	50 ft	15.24 m	0.05 in	1.27 mm	Poly-Vinyl Chloride (PVC)	Flat Cable Round Jacket		UL Style 20267	37	Enter Number of Feet in Order Quantity
3M Electronic Specialty 3659/50 1000	Copper Tinned	10 GOhm	Red	2.45 in	62.23 mm	36 AWG	7 Strands	304.8 m	1000 ft	Black	Zippable	28 AWG	-20 ░C	105 ░C	300 VDC	Shielded			0.05 in	1.27 mm	Poly-Vinyl Chloride (PVC)	Flat Cable Round Jacket		UL Style 20267	50
3M Electronic Specialty 3659/20 300SF	Copper Tinned	10 GOhm	Red	0.95 in	24.13 mm	36 AWG	7 Strands	91440 mm	3600 in	Black	Splice Free Zippable	28 AWG	-20 ░C	105 ░C	300 VDC	Shielded			0.05 in	1.27 mm	Poly-Vinyl Chloride (PVC)	Flat Cable Round Jacket		UL Style 20267	20	Enter Number of Feet in Order Quantity
3M Electronic Specialty 3659/10 100	Copper Tinned	10 GOhm	Red	0.45 in	11.43 mm	36 AWG	7 Strands	3.05 m 7.62 m 30.48 m 304.8 mm	1 ft 10 ft 25 ft 100 '	Black	Zippable	28 AWG	-20 ░C	105 ░C	300 VDC	Shielded	50 ft	15.24 m	0.05 in	1.27 mm	Poly-Vinyl Chloride (PVC)	Flat Cable Round Jacket		UL Style 20267			10
3M Electronic Specialty 3659/16 1000	Copper Tinned	10 GOhm	Red	0.75 in	19.05 mm	36 AWG	7 Strands	3.05 m 7.62 m 30.48 m 304.8 m 304.8 mm	1 ft 10 ft 25 ft 100 ' 1000 ft	Black	Zippable	28 AWG	-20 ░C	105 ░C	300 VDC	Shielded	50 ft 500 ft	15.24 m 152.4 m	0.05 in	1.27 mm	Poly-Vinyl Chloride (PVC)	Flat Cable Round Jacket		UL Style 20267	16
3M Electronic Specialty 3659/50 500SF	Copper Tinned	10 GOhm	Red	2.45 in	62.23 mm	36 AWG	7 Strands			Black	Splice Free Zippable	28 AWG	-20 ░C	105 ░C	300 VDC	Shielded	500 ft	152.4 m	0.05 in	1.27 mm	Poly-Vinyl Chloride (PVC)	Flat Cable Round Jacket		UL Style 20267	50
