P30P47 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
CONTACTOR 120VAC 4PST-NO-DM 30A FLANGE MOUNT
| Part | Coil Power | Contact Material | Switching Voltage [Max] | Contact Form | Mounting Type | Contact Rating (Current) | Termination Style | Termination Style | Coil Voltage | Operating Temperature [Max] | Operating Temperature [Min] | Must Operate Voltage | Coil Resistance | Coil Current |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 12 VA | Silver Cadmium Oxide (AgCdO) | 600 VAC | 4PST-NO (DM) (4 Form X) | Chassis Mount | 30 A | 0.25 in 6.3 mm | Screw Terminal Quick Connect | 120 VAC | 65 °C | -55 C | 94 VAC/DC | ||
 TE Connectivity AMP Connectors | 7.5 W | Silver Cadmium Oxide (AgCdO) | 600 VAC | 4PST-NO (DM) (4 Form X) | Chassis Mount | 30 A | 0.25 in 6.3 mm | Screw Terminal Quick Connect | 24 VDC | 65 °C | -55 C | 18 VDC | 84 Ohms | 286 mA |
