IPSUAT Series
Manufacturer: Sensata-Crydom
Beta
⌘K
INDUSTRIAL PRESSURE SENSORS PRESSURE
| Part | Applications | Port Size | Port Size | Port Size | Pressure Type | Port Style | Maximum Pressure | Maximum Pressure | Voltage - Supply [Min] | Voltage - Supply [Max] | Output Type | Features | Termination Style | Output [Min] | Output [Max] | Accuracy | Operating Pressure | Operating Pressure | Package / Case | Maximum Pressure [Max] | Maximum Pressure [Max] | Operating Pressure [Max] | Operating Pressure [Min] | Operating Pressure [Min] | Operating Pressure [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sensata-Crydom | Industrial Automation | Male NPT | 0.25 " | 0.25 in | Gauge | Threaded | 150 PSI | 1034.21 kPa | 10 VDC | 28 V | Analog Current | Amplified Output Temperature Compensated | Connector | 4 mA | 20 mA | 0.25 % | 517.11 kPa | 75 PSI | Chassis Mount | ||||||
 Sensata-Crydom | Industrial Automation | Male NPT | 0.25 " | 0.25 in | Gauge | Threaded | 10 VDC | 28 V | Analog Current | Amplified Output Temperature Compensated | Connector | 4 mA | 20 mA | 0.25 % | 2068.43 kPa | 300 PSI | Chassis Mount | 4136.85 kPa | 600 PSI | ||||||
Sensata-Crydom | Industrial Automation | Male NPT | 0.25 " | 0.25 in | Gauge | Threaded | 10 VDC | 28 V | Analog Current | Amplified Output Temperature Compensated | Connector | 4 mA | 20 mA | 0.25 % | 103.42 kPa | 15 PSI | Chassis Mount | 206.84 kPa | 30 PSI | ||||||
Sensata-Crydom | Industrial Automation | Male NPT | 0.25 " | 0.25 in | Compound | Threaded | 10 VDC | 28 V | Analog Current | Amplified Output Temperature Compensated | Connector | 4 mA | 20 mA | 0.25 % | Chassis Mount | 2068.43 kPa | 300 PSI | 150 PSI | -1 bar | -14.5 PSI | 1034.21 kPa | ||||
 Sensata-Crydom | Industrial Automation | Male NPT | 0.25 " | 0.25 in | Gauge | Threaded | 3000 PSI | 20684.27 kPa | 10 VDC | 28 V | Analog Current | Amplified Output Temperature Compensated | Connector | 4 mA | 20 mA | 0.25 % | 10342.14 kPa | 1500 PSI | Chassis Mount | ||||||
Sensata-Crydom | Industrial Automation | Male NPT | 0.25 " | 0.25 in | Gauge | Threaded | 6000 PSI | 41368.54 kPa | 10 VDC | 28 V | Analog Current | Amplified Output Temperature Compensated | Connector | 4 mA | 20 mA | 0.25 % | 24821.13 kPa | 3600 PSI | Chassis Mount | ||||||
Sensata-Crydom | Industrial Automation | Male NPT | 0.25 " | 0.25 in | Gauge | Threaded | 10 VDC | 28 V | Analog Current | Amplified Output Temperature Compensated | Connector | 4 mA | 20 mA | 0.25 % | 1034.21 kPa | 150 PSI | Chassis Mount | 2068.43 kPa | 300 PSI |
