RXA Series

Manufacturer: Rubycon

Catalog

ALUMINUM ELECTROLYTIC CAPACITORS - RADIAL LEADED 70VDC 750UF 20% AEC-Q200

Part	Ratings	Ripple Current @ High Frequency	ESR (Equivalent Series Resistance)	Lead Spacing	Lead Spacing	Lifetime @ Temp.	Operating Temperature [Max]	Operating Temperature [Min]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Tolerance	Ripple Current @ Low Frequency	Mounting Type	Polarization	Capacitance	Applications	Size / Dimension [diameter]	Size / Dimension [diameter]	Voltage - Rated	Package / Case	Height - Seated (Max) [Max] [custom]	Height - Seated (Max) [Max] [custom]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]
Rubycon 70RXA750MEFC16X30	AEC-Q200	2.33 A	40 mOhm	0.295 in	7.5 mm	2000 Hrs	125 °C	-40 C	1.26 in	32 mm	20 %	1.398 A	Through Hole	Polar	750 µF	Automotive	0.63 in	16 mm	70 V	Can Radial
Rubycon 25RXA2200MEFC12.5X30	AEC-Q200	2.19 A	43 mOhm	0.197 "	5 mm	3000 Hrs	125 °C	-40 C	1.26 in	32 mm	20 %	1.533 A	Through Hole	Polar	2200 µF	Automotive	0.492 in	12.5 mm	25 VDC	Can Radial
Rubycon 25RXA3300MEFC18X20	AEC-Q200	1.97 A	47 mOhm	0.295 in	7.5 mm	3000 Hrs	125 °C	-40 C			20 %	1.379 A	Through Hole	Polar	3.3 mF	Automotive	0.709 in	18 mm	25 VDC	Can Radial	0.866 in	22 mm
Rubycon 50RXA1500MEFC18X25	AEC-Q200	2.51 A	33 mOhm	0.295 in	7.5 mm	3000 Hrs	125 °C	-40 C			20 %	1.506 A	Through Hole	Polar	1.5 mF	Automotive	0.709 in	18 mm	50 VDC	Can Radial			1.063 in	27 mm
