S04B-ZES Series
Manufacturer: JST Sales America Inc.
Beta
⌘K
CONN HEADER R/A 4POS 1.5MM
| Part | Contact Material | Fastening Type | Contact Shape | Current Rating (Amps) | Contact Finish - Post | Voltage Rating | Style | Contact Length - Post [x] | Contact Length - Post | Number of Positions | Material Flammability Rating | Shrouding | Termination | Connector Type | Number of Positions Loaded | Insulation Color | Number of Rows | Mounting Type | Features | Operating Temperature [Max] | Operating Temperature [Min] | Insulation Material | Contact Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 JST Sales America Inc. | Copper Alloy | Locking Ramp | Rectangular | 2 A | Tin | 100 V | Board to Cable/Wire | 0.134 " | 3.4 mm | 4 | UL94 V-0 | Shrouded - 4 Wall | Kinked Pin Solder | Header | All | Natural | 1 | Right Angle Through Hole | Board Guide | 85 °C | -25 °C | Glass Filled Nylon 6/6 Polyamide (PA66) | Outer Shroud Contact |
