VFT150 Series
Manufacturer: XP Power
Beta
⌘K
AC/DC CONVERTER 15V 150W
| Part | Minimum Load Required | Applications | Power (Watts) | Voltage - Isolation | Voltage - Input [Max] | Voltage - Input [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Number of Outputs | Standard Number | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Voltage - Output 1 | Efficiency | Features | Type | Mounting Type | Current - Output 1 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 XP Power | ITE (Commercial) | 150 W | 3000 V | 264 VAC | 90 VAC | 70 °C | -10 °C | 1 | 62368-1 | 3 " | 127 mm | 33 mm | 5 " | 76.2 mm | 1.3 in | 15 V | 87 % | Adjustable Output Remote Sense Universal Input | Open Frame | Chassis Mount | 6.66 A | |
 XP Power | ITE (Commercial) | 150 W | 3000 V | 264 VAC | 90 VAC | 70 °C | -10 °C | 1 | 62368-1 | 3 " | 127 mm | 33 mm | 5 " | 76.2 mm | 1.3 in | 12 V | 87 % | Adjustable Output Remote Sense Universal Input | Open Frame | Chassis Mount | 8.3 A | |
 XP Power | ITE (Commercial) | 150 W | 3000 V | 264 VAC | 90 VAC | 70 °C | -10 °C | 1 | 62368-1 | 3 " | 127 mm | 33 mm | 5 " | 76.2 mm | 1.3 in | 5 V | 83 % | Adjustable Output Remote Sense Universal Input | Open Frame | Chassis Mount | 24 A |
