346-87 Series
Manufacturer: Preci-Dip
Beta
⌘K
CONN SOCKET 24POS 0.1 GOLD PCB
| Part | Insulation Material | Contact Material | Contact Shape | Number of Positions | Contact Type | Connector Type | Contact Finish - Mating | Material Flammability Rating | Insulation Color | Contact Finish - Post | Number of Rows | Contact Length - Post [custom] | Contact Length - Post | Pitch - Mating | Pitch - Mating | Number of Positions Loaded | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish Thickness - Mating | Fastening Type | Mounting Type | Insulation Height | Insulation Height | Current Rating (Amps) | Termination | Number of Positions [custom] | Insulation Height | Contact Length - Post [x] | Contact Length - Post [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Circular | 24 | Female Socket | Socket | Gold | UL94 V-0 | Black | Tin | 1 | 0.11 in | 2.79 mm | 0.1 " | 2.54 mm | All | -55 C | 125 °C | Flash | Push-Pull | Through Hole | 0.116 " | 2.95 mm | 3 A | Press-Fit Solder | ||||
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Circular | Female Socket | Socket | Gold | UL94 V-0 | Black | Tin | 1 | 0.11 in | 2.79 mm | 0.1 " | 2.54 mm | All | -55 C | 125 °C | Flash | Push-Pull | Through Hole | 0.116 " | 2.95 mm | 3 A | Press-Fit Solder | 33 | ||||
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Circular | 13 | Female Socket | Socket | Gold | UL94 V-0 | Black | Tin | 1 | 0.1 " | 2.54 mm | All | -55 C | 125 °C | Flash | Push-Pull | Through Hole | 0.173 in | 3 A | Press-Fit Solder | 4.4 mm | 3.81 mm | 0.15 in | ||||
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Circular | 57 | Female Socket | Socket | Gold | UL94 V-0 | Black | Tin | 1 | 0.1 " | 2.54 mm | All | -55 C | 125 °C | Flash | Push-Pull | Through Hole | 0.173 in | 3 A | Press-Fit Solder | 4.4 mm | 3.81 mm | 0.15 in | ||||
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Circular | 53 | Female Socket | Socket | Gold | UL94 V-0 | Black | Tin | 1 | 0.1 " | 2.54 mm | All | -55 C | 125 °C | Flash | Push-Pull | Through Hole | 0.173 in | 3 A | Press-Fit Solder | 4.4 mm | 3.81 mm | 0.15 in | ||||
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Circular | 15 | Female Socket | Socket | Gold | UL94 V-0 | Black | Tin | 1 | 0.11 in | 2.79 mm | 0.1 " | 2.54 mm | All | -55 C | 125 °C | Flash | Push-Pull | Through Hole | 0.116 " | 2.95 mm | 3 A | Press-Fit Solder | ||||
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Circular | 22 | Female Socket | Socket | Gold | UL94 V-0 | Black | Tin | 1 | 0.11 in | 2.79 mm | 0.1 " | 2.54 mm | All | -55 C | 125 °C | Flash | Push-Pull | Through Hole | 0.116 " | 2.95 mm | 3 A | Press-Fit Solder | ||||
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Circular | 19 | Female Socket | Socket | Gold | UL94 V-0 | Black | Tin | 1 | 0.11 in | 2.79 mm | 0.1 " | 2.54 mm | All | -55 C | 125 °C | Flash | Push-Pull | Through Hole | 0.116 " | 2.95 mm | 3 A | Press-Fit Solder | ||||
 Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Circular | 4 | Female Socket | Socket | Gold | UL94 V-0 | Black | Tin | 1 | 0.11 in | 2.79 mm | 0.1 " | 2.54 mm | All | -55 C | 125 °C | Flash | Push-Pull | Through Hole | 0.116 " | 2.95 mm | 3 A | Press-Fit Solder | ||||
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Circular | 20 | Female Socket | Socket | Gold | UL94 V-0 | Black | Tin | 1 | 0.1 " | 2.54 mm | All | -55 C | 125 °C | Flash | Push-Pull | Through Hole | 0.173 in | 3 A | Press-Fit Solder | 4.4 mm | 3.81 mm | 0.15 in |
