5199/10C Series
Manufacturer: ALPHA WIRE
Beta
⌘K
CBL 10COND 22AWG SHLD 1000=1000'
| Part | Shield Material | Shield Coverage | Usage | Cable Type | Voltage | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Wire Gauge | Operating Temperature [Min] | Operating Temperature [Max] | Number of Conductors [custom] | Jacket Color | Shield Type | Ratings | Jacket (Insulation) Material | Conductor Insulation | Features | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Conductor Material | Conductor Strand [custom] | Conductor Strand [custom] | Length | Length | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ALPHA WIRE | Aluminum | 100 % | Communication Control | Multi-Conductor | 300 VDC | 0.813 mm | 0.032 in | 22 AWG | -35 °C | 105 ░C | 10 | Slate | Foil | ISO 10993 | Poly-Vinyl Chloride (PVC) | Poly-Vinyl Chloride (PVC) | Biological Compatibility Drain Wire Rip Cord | 0.272 in | 6.91 mm | Copper Tinned | 30 AWG | 7 | ||||
 ALPHA WIRE | Aluminum | 100 % | Communication Control | Multi-Conductor | 300 VDC | 0.813 mm | 0.032 in | 22 AWG | -35 °C | 105 ░C | 10 | Slate | Foil | ISO 10993 | Poly-Vinyl Chloride (PVC) | Poly-Vinyl Chloride (PVC) | Biological Compatibility Drain Wire Rip Cord | 0.272 in | 6.91 mm | Copper Tinned | 30 AWG | 7 | 152.4 m | 500 ft | ||
ALPHA WIRE | Aluminum | 100 % | Communication Control | Multi-Conductor | 300 VDC | 0.813 mm | 0.032 in | 22 AWG | -35 °C | 105 ░C | 10 | Slate | Foil | ISO 10993 | Poly-Vinyl Chloride (PVC) | Poly-Vinyl Chloride (PVC) | Biological Compatibility Drain Wire Rip Cord | 0.272 in | 6.91 mm | Copper Tinned | 30 AWG | 7 | 100 ft | 30.5 m |
