1761603 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

CONN HEADER VERT 30POS 2.54MM

Part	Fastening Type	Mounting Type	Contact Length - Post	Contact Length - Post	Contact Length - Mating	Contact Length - Mating [x]	Number of Rows	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Material Flammability Rating	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Finish - Mating	Pitch - Mating	Pitch - Mating	Number of Positions Loaded	Features	Contact Material	Current Rating (Amps)	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Type	Termination	Contact Shape	Number of Positions	Voltage Rating	Insulation Color	Style	Shrouding	Contact Finish - Post	Insulation Height [custom]	Insulation Height [custom]	Connector Type	Insulation Material	Number of Positions
TE Connectivity Raychem Cable Protection 3-1761603-0	Push-Pull	Through Hole	0.102 in	2.6 mm	6.1 mm	0.24 in	2	-65 ░C	105 ░C	2.54 µm	100 µin	UL94 V-0	30 Áin	0.76 Ám	Gold	0.1 in	2.54 mm	All	Keying Slot	Phosphor Bronze	1 A	2.54 mm	0.1 in	Male Pin	Solder	Square	30	250 VAC	Blue	Board to Cable/Wire	Shrouded - 4 Wall	Tin	0.35 in	8.89 mm	Header	Polybutylene Terephthalate (PBT)
TE Connectivity Raychem Cable Protection 3-1761603-4	Push-Pull	Through Hole	0.102 in	2.6 mm	6.1 mm	0.24 in	2	-65 ░C	105 ░C	2.54 µm	100 µin	UL94 V-0	30 Áin	0.76 Ám	Gold	0.1 in	2.54 mm	All	Keying Slot	Phosphor Bronze	1 A	2.54 mm	0.1 in	Male Pin	Solder	Square	44	250 VAC	Blue	Board to Cable/Wire	Shrouded - 4 Wall	Tin	0.35 in	8.89 mm	Header	Polybutylene Terephthalate (PBT)
TE Connectivity Raychem Cable Protection 3-1761603-5	Push-Pull	Through Hole	0.102 in	2.6 mm	6.1 mm	0.24 in	2	-65 ░C	105 ░C	2.54 µm	100 µin	UL94 V-0	30 Áin	0.76 Ám	Gold	0.1 in	2.54 mm	All	Keying Slot	Phosphor Bronze	1 A	2.54 mm	0.1 in	Male Pin	Solder	Square	50	250 VAC	Blue	Board to Cable/Wire	Shrouded - 4 Wall	Tin	0.35 in	8.89 mm	Header	Polybutylene Terephthalate (PBT)
TE Connectivity Raychem Cable Protection 2-1761603-7	Push-Pull	Through Hole	0.102 in	2.6 mm	6.1 mm	0.24 in	2	-65 ░C	105 ░C	2.54 µm	100 µin	UL94 V-0	30 Áin	0.76 Ám	Gold	0.1 in	2.54 mm	All	Keying Slot	Phosphor Bronze	1 A	2.54 mm	0.1 in	Male Pin	Solder	Square	20	250 VAC	Blue	Board to Cable/Wire	Shrouded - 4 Wall	Tin	0.35 in	8.89 mm	Header	Polybutylene Terephthalate (PBT)
TE Connectivity Raychem Cable Protection 3-1761603-3	Push-Pull	Through Hole	0.102 in	2.6 mm	6.1 mm	0.24 in	2	-65 ░C	105 ░C	2.54 µm	100 µin	UL94 V-0	30 Áin	0.76 Ám	Gold	0.1 in	2.54 mm	All	Keying Slot	Phosphor Bronze	1 A	2.54 mm	0.1 in	Male Pin	Solder	Square	40	250 VAC	Blue	Board to Cable/Wire	Shrouded - 4 Wall	Tin	0.35 in	8.89 mm	Header	Polybutylene Terephthalate (PBT)
TE Connectivity Raychem Cable Protection 2-1761603-3	Push-Pull	Through Hole	0.102 in	2.6 mm	6.1 mm	0.24 in	2	-65 ░C	105 ░C	2.54 µm	100 µin	UL94 V-0	30 Áin	0.76 Ám	Gold	0.1 in	2.54 mm	All	Keying Slot	Phosphor Bronze	1 A	2.54 mm	0.1 in	Male Pin	Solder	Square	10	250 VAC	Blue	Board to Cable/Wire	Shrouded - 4 Wall	Tin	0.35 in	8.89 mm	Header	Polybutylene Terephthalate (PBT)
TE Connectivity Raychem Cable Protection 1-1761603-3	Push-Pull	Through Hole	0.102 in	2.6 mm	6.1 mm	0.24 in	2	-65 ░C	105 ░C	2.54 µm	100 µin	UL94 V-0	30 Áin	0.76 Ám	Gold	0.1 in	2.54 mm	All	Keying Slot	Phosphor Bronze	1 A	2.54 mm	0.1 in	Male Pin	Solder	Square	40	250 VAC	Black	Board to Cable/Wire	Shrouded - 4 Wall	Tin	0.35 in	8.89 mm	Header	Polybutylene Terephthalate (PBT)
TE Connectivity Raychem Cable Protection 1761603-7	Push-Pull	Through Hole	0.102 in	2.6 mm	6.1 mm	0.24 in	2	-65 ░C	105 ░C	2.54 µm	100 µin	UL94 V-0	30 Áin	0.76 Ám	Gold	0.1 in	2.54 mm	All	Keying Slot	Phosphor Bronze	1 A	2.54 mm	0.1 in	Male Pin	Solder	Square	20	250 VAC	Black	Board to Cable/Wire	Shrouded - 4 Wall	Tin	0.35 in	8.89 mm	Header	Polybutylene Terephthalate (PBT)
TE Connectivity Raychem Cable Protection 1761603-6	Push-Pull	Through Hole	0.102 in	2.6 mm	6.1 mm	0.24 in	2	-65 ░C	105 ░C	2.54 µm	100 µin	UL94 V-0	30 Áin	0.76 Ám	Gold	0.1 in	2.54 mm	All	Keying Slot	Phosphor Bronze	1 A	2.54 mm	0.1 in	Male Pin	Solder	Square		250 VAC	Black	Board to Cable/Wire	Shrouded - 4 Wall	Tin	0.35 in	8.89 mm	Header	Polybutylene Terephthalate (PBT)	16
TE Connectivity Raychem Cable Protection 1761603-3	Push-Pull	Through Hole	0.102 in	2.6 mm	6.1 mm	0.24 in	2	-65 ░C	105 ░C	2.54 µm	100 µin	UL94 V-0	30 Áin	0.76 Ám	Gold	0.1 in	2.54 mm	All	Keying Slot	Phosphor Bronze	1 A	2.54 mm	0.1 in	Male Pin	Solder	Square	10	250 VAC	Black	Board to Cable/Wire	Shrouded - 4 Wall	Tin	0.35 in	8.89 mm	Header	Polybutylene Terephthalate (PBT)
