3RT2025 Series

Manufacturer: Siemens

Catalog

Catalog

CONTACTOR S0 16A 230VAC 2NO/2NC

...

Part	Coil Power	Operate Time	Release Time	Switching Voltage [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Contact Rating (Current)	Mounting Type	Must Operate Voltage	Contact Form	Coil Voltage	Features	Termination Style	Coil Voltage [Min]	Coil Voltage [Max]
Siemens 3RT20252AL243MA0	67 VA	40 ms	16 ms	690 VAC	-25 °C	60 °C	17 A	Chassis Mount DIN Rail	195.5 VAC	3PST-NO (3 Form A)	230 VAC	Auxiliary Contacts	Screw Terminal
Siemens 3RT20251BP40	5.9 W	170 ms	17.5 ms	690 VAC	-25 °C	60 °C	17 A	Chassis Mount DIN Rail	184 VDC	3PST-NO (3 Form A)	230 VDC	Auxiliary Contacts	Screw Terminal
Siemens 3RT20252KF40	4.5 W	270 ms	21 ms	690 VAC	-25 °C	60 °C	17 A	Chassis Mount DIN Rail	77 VDC	3PST-NO (3 Form A)	110 VDC	Auxiliary Contacts	Screw Terminal
Siemens 3RT20252AM20	67 VA	40 ms	16 ms	690 VAC	-25 °C	60 °C	17 A	Chassis Mount DIN Rail	176.8 VAC	3PST-NO (3 Form A)	208 VAC	Auxiliary Contacts	Spring Terminal
Siemens 3RT20251BA40	5.9 W	170 ms	17.5 ms	690 VAC	-25 °C	60 °C	17 A	Chassis Mount DIN Rail	9.6 VDC	3PST-NO (3 Form A)	12 VDC	Auxiliary Contacts	Screw Terminal
Siemens 3RT20251AU00	65 VA	40 ms	16 ms	690 VAC	-25 °C	60 °C	17 A	Chassis Mount DIN Rail	192 VAC	3PST-NO (3 Form A)	240 VAC/DC	Auxiliary Contacts	Screw Terminal
Siemens 3RT20252AB00	65 VA	40 ms	16 ms	690 VAC	-25 °C	60 °C	17 A	Chassis Mount DIN Rail	19.2 VAC	3PST-NO (3 Form A)	24 VAC	Auxiliary Contacts	Spring Terminal
Siemens 3RT20252NF30	10.2 W	80 ms	50 ms	690 VAC	-25 °C	60 °C	17 A	Chassis Mount DIN Rail		3PST-NO (3 Form A)		Auxiliary Contacts	Screw Terminal	95 VAC	130 VAC/DC
Siemens 3RT20251AH00	65 VA	40 ms	16 ms	690 VAC	-25 °C	60 °C	17 A	Chassis Mount DIN Rail	38.4 VAC	3PST-NO (3 Form A)	48 VAC	Auxiliary Contacts	Screw Terminal
Siemens 3RT20251AL243MA0	67 VA	40 ms	16 ms	690 VAC	-25 °C	60 °C	17 A	Chassis Mount DIN Rail	195.5 VAC	3PST-NO (3 Form A)	230 VAC	Auxiliary Contacts	Screw Terminal
