846-019 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 19POS 0.125
| Part | Termination Rows | Material - Insulation | Gender | Operating Temperature [Max] | Operating Temperature [Min] | Termination | Pitch | Pitch | Contact Type | Number of Positions/Bay/Row | Contact Material | Number of Rows | Card Thickness [Max] | Card Thickness [Min] | Read Out | Mounting Type | Color | Card Type | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Contact Finish | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 125 °C | -40 C | Solder Eyelet(s) | 3.18 mm | 0.125 in | Cantilever | 19 | Copper Alloy | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Through Hole | Green | Non Specified - Single Edge | 19 | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | Gold | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 125 °C | -40 C | Solder | 3.18 mm | 0.125 in | Cantilever | 19 | Copper Alloy | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Through Hole | Green | Non Specified - Single Edge | 19 | 0.25 Ám | 10 Áin | Flush Mount Side Opening Unthreaded | Gold | 0.128 " | 3.25 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 125 °C | -40 C | Solder | 3.18 mm | 0.125 in | Cantilever | 19 | Copper Alloy | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Through Hole | Green | Non Specified - Single Edge | 19 | 0.25 Ám | 10 Áin | Flush Mount M3 Threaded Insert Top Opening | Gold | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 125 °C | -40 C | Solder | 3.18 mm | 0.125 in | Cantilever | 19 | Copper Alloy | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Through Hole | Green | Non Specified - Single Edge | 19 | 0.25 Ám | 10 Áin | Flush Mount Side Opening Unthreaded | Gold | 0.128 " | 3.25 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 125 °C | -40 C | Solder | 3.18 mm | 0.125 in | Cantilever | 19 | Copper Alloy | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Right Angle Through Hole | Green | Non Specified - Single Edge | 19 | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | Gold | 0.156 " | 3.96 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 125 °C | -40 C | Solder Eyelet(s) | 3.18 mm | 0.125 in | Cantilever | 19 | Copper Alloy | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Through Hole | Green | Non Specified - Single Edge | 19 | 0.25 Ám | 10 Áin | Flush Mount M3 Threaded Insert Top Opening | Gold | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 125 °C | -40 C | Solder | 3.18 mm | 0.125 in | Cantilever | 19 | Copper Alloy | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Through Hole | Green | Non Specified - Single Edge | 19 | 0.25 Ám | 10 Áin | M3 Threaded Insert Top Mount Opening | Gold | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 125 °C | -40 C | Solder | 3.18 mm | 0.125 in | Cantilever | 19 | Copper Alloy | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Through Hole | Green | Non Specified - Single Edge | 19 | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | Gold | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 125 °C | -40 C | Solder Eyelet(s) | 3.18 mm | 0.125 in | Cantilever | 19 | Copper Alloy | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Through Hole | Green | Non Specified - Single Edge | 19 | 0.25 Ám | 10 Áin | Gold | 0.156 " | 3.96 mm | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Female | 125 °C | -40 C | Solder | 3.18 mm | 0.125 in | Cantilever | 19 | Copper Alloy | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | Right Angle Through Hole | Green | Non Specified - Single Edge | 19 | 0.25 Ám | 10 Áin | Floating Bobbin Flush Mount | Gold | 0.116 " | 2.95 mm |
