892-052 Series
Manufacturer: EDAC Inc.
Catalog
CONN EDGE SINGLE FML 52POS 0.100
...
| Part | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Number of Rows | Contact Finish | Number of Positions/Bay/Row | Card Thickness [Max] | Card Thickness [Min] | Termination Rows | Termination | Gender | Card Type | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Contact Type | Pitch | Pitch | Read Out | Material - Insulation | Color | Mounting Type | Number of Positions | Termination Rows [custom] | Number of Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | 1 | Gold | 52 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Solder | Female | Non Specified - Single Edge | 125 °C | -40 C | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | Single | Polyphenylene Sulfide (PPS) | Black | Through Hole | 52 | ||||
 EDAC Inc. | 0.25 Ám | 10 Áin | Flush Mount M3 Threaded Insert Top Opening | 1 | Gold | 52 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Solder | Female | Non Specified - Single Edge | 125 °C | -40 C | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | Single | Polyphenylene Sulfide (PPS) | Black | Through Hole | 52 | ||||
 EDAC Inc. | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | Gold | 26 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | Female | Non Specified - Dual Edge | 125 °C | -40 C | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | Dual | Polyphenylene Sulfide (PPS) | Black | Through Hole | 52 | 2 | 2 | ||||
 EDAC Inc. | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | Gold | 26 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Female | Non Specified - Dual Edge | 125 °C | -40 C | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | Dual | Polyphenylene Sulfide (PPS) | Black | Through Hole | 52 | 2 | 2 | 0.156 " | 3.96 mm | ||
 EDAC Inc. | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | Gold | 26 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Female | Non Specified - Dual Edge | 125 °C | -40 C | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | Dual | Polyphenylene Sulfide (PPS) | Black | Right Angle Through Hole | 52 | 2 | 2 | ||||
 EDAC Inc. | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | Gold | 26 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | Female | Non Specified - Dual Edge | 125 °C | -40 C | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | Dual | Polyphenylene Sulfide (PPS) | Black | Through Hole | 52 | 2 | 2 | ||||
 EDAC Inc. | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | 1 | Gold | 52 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Solder Eyelet(s) | Female | Non Specified - Single Edge | 125 °C | -40 C | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | Single | Polyphenylene Sulfide (PPS) | Black | Through Hole | 52 | 0.128 " | 3.25 mm | ||
 EDAC Inc. | 0.25 Ám | 10 Áin | Flush Mount Side Opening Unthreaded | 1 | Gold | 52 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Solder | Female | Non Specified - Single Edge | 125 °C | -40 C | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | Single | Polyphenylene Sulfide (PPS) | Black | Right Angle Through Hole | 52 | 0.128 " | 3.25 mm | ||
 EDAC Inc. | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | Gold | 26 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Female | Non Specified - Dual Edge | 125 °C | -40 C | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | Dual | Polyphenylene Sulfide (PPS) | Black | Right Angle Through Hole | 52 | 2 | 2 | 0.128 " | 3.25 mm | ||
 EDAC Inc. | 0.25 Ám | 10 Áin | Gold | 26 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Female | Non Specified - Dual Edge | 125 °C | -40 C | Copper Alloy | Cantilever | 0.1 " | 2.54 mm | Dual | Polyphenylene Sulfide (PPS) | Black | Through Hole | 52 | 2 | 2 |
