QPS-35 Series
Manufacturer: Qualtek
Beta
⌘K
AC/DC CONVERTER 36V 36W
| Part | Minimum Load Required | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Mounting Type | Number of Outputs | Applications | Power (Watts) | Efficiency | Approval Agency | Voltage - Output 1 [custom] | Voltage - Input [Max] | Voltage - Input [Min] | Voltage - Isolation | Features | Type | Current - Output 1 | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Output 1 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Qualtek | 2.01 in 51 mm | 101.6 mm | 0.99 " 25.1 mm | Chassis Mount | 1 | ITE (Commercial) | 36 W | 84 % | CB CE cURus | 36 V | 264 VAC | 90 VAC | 3000 V | Adjustable Output Universal Input | Open Frame | 1 A | -20 °C | 65 °C | ||
Qualtek | 2.01 in 51 mm | 101.6 mm | 0.99 " 25.1 mm | Chassis Mount | 1 | ITE (Commercial) | 30 Watts | 78 % | CB CE cURus | 264 VAC | 90 VAC | 3000 V | Adjustable Output Universal Input | Open Frame | 6 A | -20 °C | 65 °C | 5 V | ||
Qualtek | 2.01 in 51 mm | 101.6 mm | 0.99 " 25.1 mm | Chassis Mount | 1 | ITE (Commercial) | 36 W | 86 % | CB CE cURus | 264 VAC | 90 VAC | 3000 V | Adjustable Output Universal Input | Open Frame | 750 mA | -20 °C | 65 °C | 48 V | ||
Qualtek | 2.01 in 51 mm | 101.6 mm | 0.99 " 25.1 mm | Chassis Mount | 1 | ITE (Commercial) | 36 W | 83 % | CB CE cURus | 264 VAC | 90 VAC | 3000 V | Adjustable Output Universal Input | Open Frame | 1.5 A | -20 °C | 65 °C | 24 V |
