164 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
SWITCH PUSH 6PST-3NO/3NC 5A 250V
| Part | Electrical Life | Current Rating (Amps) | Actuator Type | Panel Cutout Dimensions [diameter] | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Rating - AC | Termination Style | Circuit | Voltage Rating - DC | Ingress Protection | Actuator Marking | Switch Function | Type | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 100000 Cycles | 5 A | Button Square | 16 mm | -20 ░C | 50 °C | 250 V | Solder Lug | 6PST-3NO/3NC | 24 V | IP65 - Dust Tight Water Resistant | No Marking | Off-On On-Off | Illuminated Standard | Panel Mount Front |
 TE Connectivity AMP Connectors | 100000 Cycles | 5 A | Button Square | 16 mm | -20 ░C | 50 °C | 250 V | Solder Lug | 4PST-2NO/2NC | 24 V | IP65 - Dust Tight Water Resistant | No Marking | Off-On On-Off | Illuminated Standard | Panel Mount Front |
TE Connectivity AMP Connectors | 100000 Cycles | 5 A | Button Square | 16 mm | -20 ░C | 50 °C | 250 V | Solder Lug | DPST-NO/NC | 24 V | IP65 - Dust Tight Water Resistant | No Marking | Off-Mom On-Mom | Illuminated Standard | Panel Mount Front |
 TE Connectivity AMP Connectors | 100000 Cycles | 5 A | Button Rectangular | 16 mm | -20 ░C | 50 °C | 250 V | Solder Lug | DPST-NO/NC | 24 V | IP65 - Dust Tight Water Resistant | No Marking | Off-On On-Off | Illuminated Standard | Panel Mount Front |
TE Connectivity AMP Connectors | 100000 Cycles | 5 A | Button Rectangular | 16 mm | -20 ░C | 50 °C | 250 V | Solder Lug | 6PST-3NO/3NC | 24 V | IP65 - Dust Tight Water Resistant | No Marking | Off-Mom On-Mom | Illuminated Standard | Panel Mount Front |
