FDLL4448 Series

Small Signal Diode

Catalog

Small Signal Diode

Part	Speed	Speed	Supplier Device Package	Voltage - DC Reverse (Vr) (Max) [Max]	Technology	Current - Average Rectified (Io)	Package / Case	Mounting Type	Operating Temperature - Junction [Max]	Operating Temperature - Junction [Min]	Capacitance @ Vr, F	Reverse Recovery Time (trr)	Voltage - Forward (Vf) (Max) @ If	Current - Reverse Leakage @ Vr
ON Semiconductor FDLL4448-D87Z	Any Speed	200 mA	SOD-80	100 V	Standard	200 mA	DO-213AC MINI-MELF SOD-80	Surface Mount	175 ░C	-55 C	2 pF	4 ns	1 V	5 µA
ON Semiconductor FDLL4448	Any Speed	200 mA	SOD-80	100 V	Standard	200 mA	DO-213AC MINI-MELF SOD-80	Surface Mount	175 ░C	-55 C	2 pF	4 ns	1 V	5 µA

Small Signal Diode
