CHM-9-30 Series

Catalog

LED COB CHM9 GEN2 WHT SQ 3000K

Part	Configuration	Features	CRI (Color Rendering Index)	Voltage - Forward (Vf) (Typ)	CCT (K)	CCT (K)	Viewing Angle	Type	Lens Type	Luminous Flux @ Current/Temperature	Temperature - Test	Size / Dimension [y]	Size / Dimension [x]	Height [z]	Color	Light Emitting Surface (LES) [diameter]	Lumens/Watt @ Current - Test	Current - Max [Max]	Current - Test
Luminus Devices Inc. CHM-9-30-95-18-AA10-F3-3	Square	With Connector	95	18 V	3-Step MacAdam Ellipse	3000 K	120 °	Chip On Board (COB)	Flat	1220 lm	85 °C	15 mm	15 mm	1.37 mm	Warm White	8.9 mm
Luminus Devices Inc. CHM-9-30-80-36-AC02-F2-3	Square		80	35 V	3-Step MacAdam Ellipse	3000 K	120 °	Chip On Board (COB)	Flat	1310 lm	85 °C	13.5 mm	13.5 mm	1.37 mm	Warm White	9 mm	104 lm/W	550 mA	360 mA
Luminus Devices Inc. CHM-9-30-90-36-XH24-F3-3	Square	With Connector	90	36.5 V	3-Step MacAdam Ellipse	3000 K	120 °	Chip On Board (COB)	Flat	2205 lm	85 °C	19 mm	19 mm	1.37 mm	Warm White	8.9 mm	84 lm/W	1.08 A	720 mA
Luminus Devices Inc. CHM-9-30-80-36-AC02-F2-2	Square		80	35 V		3000 K	120 °	Chip On Board (COB)	Flat	1380 lm	85 °C	13.5 mm	13.5 mm	1.37 mm	Warm White	9 mm	110 lm/W	720 mA	360 mA
Luminus Devices Inc. CHM-9-30-90-36-XH00-F1-3	Square		90	36 V	3-Step MacAdam Ellipse	3000 K	120 °	Chip On Board (COB)	Flat		85 °C	19 mm	19 mm	1.37 mm	Warm White	9 mm		1.05 A	720 mA
Luminus Devices Inc. CHM-9-30-90-36-AC00-F2-2	Square		90	35 V		3000 K	120 °	Chip On Board (COB)	Flat	1170 lm	85 °C	13.5 mm	13.5 mm	1.37 mm	Warm White	9 mm	93 lm/W	720 mA	360 mA
Luminus Devices Inc. CHM-9-30-80-18-AA00-F2-3	Square		80	18 V	3-Step MacAdam Ellipse	3000 K	120 °	Chip On Board (COB)	Flat		85 °C	13.5 mm	13.5 mm	1.37 mm	Warm White	9 mm		545 mA	360 mA
Luminus Devices Inc. CHM-9-30-95-18-AC10-F3-3	Square		95	18 V	3-Step MacAdam Ellipse	3000 K	120 °	Chip On Board (COB)	Flat		85 °C	13.5 mm	13.5 mm	1.37 mm	Warm White	9 mm		545 mA	360 mA
Luminus Devices Inc. CHM-9-30-80-36-AA12-F3-3	Square		80	34.5 V	3-Step MacAdam Ellipse	3000 K	120 °	Chip On Board (COB)	Flat	1530 lm	85 °C	15 mm	15 mm	1.37 mm	Warm White	9 mm	123 lm/W	720 mA	360 mA
Luminus Devices Inc. CHM-9-30-90-36-AC00-F2-3	Square		90	35 V	3-Step MacAdam Ellipse	3000 K	120 °	Chip On Board (COB)	Flat	1170 lm	85 °C	13.5 mm	13.5 mm	1.37 mm	Warm White	9 mm	93 lm/W	720 mA	360 mA
