002230 Series

Manufacturer: Molex

Catalog

CONN UNSHROUDED HEADER HDR 5 POS 2.54MM SOLDER ST TOP ENTRY THRU-HOLE KK BULK

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Applications	Material Flammability Rating	Number of Rows	Mounting Type	Insulation Color	Overall Contact Length	Overall Contact Length	Fastening Type	Number of Positions Loaded	Contact Type	Style	Contact Length - Post [custom]	Contact Length - Post [custom]	Contact Length - Mating	Contact Length - Mating	Shrouding	Contact Finish - Post	Termination	Number of Positions	Connector Type	Contact Shape	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Insulation Material	Pitch - Mating	Pitch - Mating	Insulation Height [z]	Insulation Height [z]	Contact Length - Post	Contact Length - Post	Number of Positions Loaded	Contact Length - Mating [x]	Contact Length - Mating [x]	Contact Finish - Mating
Molex 0022303053	2.54 µm	100 µin	Automotive General Purpose Medical Telecommunications	UL94 V-0	1	Through Hole	Black	0.63 in	16 mm	Push-Pull	All	Male Pin	Board to Board Cable	0.135 in	3.43 mm	10.29 mm	0.405 in	Unshrouded	Tin	Kinked Pin Solder	5	Header Breakaway	Square	100 çin	2.54 çm	Glass Filled Nylon Polyamide (PA)	0.1 "	2.54 mm	0.09 in	2.29 mm
Molex 0022303063	2.54 µm	100 µin	Automotive General Purpose Medical Telecommunications	UL94 V-0	1	Through Hole	Black	0.63 in	16 mm	Push-Pull	All	Male Pin	Board to Board Cable	0.135 in	3.43 mm	10.29 mm	0.405 in	Unshrouded	Tin	Kinked Pin Solder	6	Header Breakaway	Square	100 çin	2.54 çm	Glass Filled Nylon Polyamide (PA)	0.1 "	2.54 mm	0.09 in	2.29 mm
Molex 0022303163	2.54 µm	100 µin	Automotive General Purpose Medical Telecommunications	UL94 V-0	1	Through Hole	Black	0.63 in	16 mm	Push-Pull	All	Male Pin	Board to Board Cable	0.135 in	3.43 mm	10.29 mm	0.405 in	Unshrouded	Tin	Kinked Pin Solder	16	Header Breakaway	Square	100 çin	2.54 çm	Glass Filled Nylon Polyamide (PA)	0.1 "	2.54 mm	0.09 in	2.29 mm
Molex 0022303364	2.54 µm	100 µin	Automotive General Purpose Medical Telecommunications	UL94 V-0	1	Through Hole	Black	0.53 in	13.46 mm	Push-Pull		Male Pin	Board to Board Cable			8.13 mm	0.32 in	Unshrouded	Tin	Solder	36	Header Breakaway	Square	100 çin	2.54 çm	Glass Filled Nylon Polyamide (PA)	0.1 "	2.54 mm	0.09 in	2.29 mm	3.05 mm	0.12 in	35
Molex 0022303043	2.54 µm	100 µin	Automotive General Purpose Medical Telecommunications	UL94 V-0	1	Through Hole	Black	0.63 in	16 mm	Push-Pull	All	Male Pin	Board to Board Cable	0.135 in	3.43 mm	10.29 mm	0.405 in	Unshrouded	Tin	Kinked Pin Solder	4	Header Breakaway	Square	100 çin	2.54 çm	Glass Filled Nylon Polyamide (PA)	0.1 "	2.54 mm	0.09 in	2.29 mm
Molex 0022303061	2.54 µm	100 µin	Automotive General Purpose Medical Telecommunications	UL94 V-0	1	Through Hole	Black	0.465 in	11.81 mm	Push-Pull		Male Pin	Board to Board Cable	0.135 in	3.43 mm			Unshrouded	Tin	Kinked Pin Solder	6	Header Breakaway	Square	15 µin	0.38 µm	Glass Filled Nylon Polyamide (PA)	0.1 "	2.54 mm	0.09 in	2.29 mm			5	0.24 in	6.1 mm	Gold
Molex 0022303363	2.54 µm	100 µin	Automotive General Purpose Medical Telecommunications	UL94 V-0	1	Through Hole	Black	0.63 in	16 mm	Push-Pull	All	Male Pin	Board to Board Cable	0.135 in	3.43 mm	10.29 mm	0.405 in	Unshrouded	Tin	Kinked Pin Solder	36	Header Breakaway	Square	100 çin	2.54 çm	Glass Filled Nylon Polyamide (PA)	0.1 "	2.54 mm	0.09 in	2.29 mm
Molex 0022303107	2.54 µm	100 µin	Automotive General Purpose Medical Telecommunications	UL94 V-0	1	Through Hole	Black	0.455 in	11.56 mm	Push-Pull		Male Pin	Board to Board Cable			11.56 mm	0.455 in	Unshrouded	Tin	Solder	10	Header Breakaway	Square	100 çin	2.54 çm	Glass Filled Nylon Polyamide (PA)	0.1 "	2.54 mm	0.09 in	2.29 mm	3.18 mm	0.125 in	8
Molex 0022303034	2.54 µm	100 µin	Automotive General Purpose Medical Telecommunications	UL94 V-0	1	Through Hole	Black	0.53 in	13.46 mm	Push-Pull		Male Pin	Board to Board Cable			8.13 mm	0.32 in	Unshrouded	Tin	Solder		Header Breakaway	Square	100 çin	2.54 çm	Glass Filled Nylon Polyamide (PA)	0.1 "	2.54 mm	0.09 in	2.29 mm	3.05 mm	0.12 in	2
