SC02D Series

Catalog

DC DC CONVERTER +/-15V 2W

Part	Current - Output (Max)	Voltage - Isolation	Voltage - Output 1	Applications	Package / Case	Voltage - Output 2	Mounting Type	Features	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Efficiency	Type	Number of Outputs	Voltage - Input (Min) [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Power (Watts)	Voltage - Input (Max) [Max]	Current - Output (Max)
Delta Electronics SC02D0515A	66 mA	1000 V	15 V	Medical	8-SMD Module 5 Leads	-15 V	Surface Mount	SCP	0.5 "	9.3 mm	0.35 in	0.37 in	9 mm	12.8 mm	79 %	Isolated Module	2	4.5 V	85 °C	-40 C	2 W	5.5 V
Delta Electronics SC02D1215A	66 mA	1000 V	15 V	Medical	8-SMD Module 5 Leads	-15 V	Surface Mount	SCP	0.5 "	9.3 mm	0.35 in	0.37 in	9 mm	12.8 mm		Isolated Module	2	10.8 V	85 °C	-40 C	2 W	13.2 V
Delta Electronics SC02D1212A	83 mA	1000 V	12 V	Medical	8-SMD Module 5 Leads	-12 V	Surface Mount	SCP	0.5 "	9.3 mm	0.35 in	0.37 in	9 mm	12.8 mm		Isolated Module	2	10.8 V	85 °C	-40 C	2 W	13.2 V	83 mA
