837-016 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 16POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Pitch | Pitch | Contact Type | Number of Positions/Bay/Row | Color | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Card Type | Termination | Features | Read Out | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Gender | Mounting Type | Termination Rows | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | Cantilever | 8 | Green | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Non Specified - Dual Edge | Solder | Card Extender | Dual | 125 °C | -40 C | 16 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Gold | 0.25 Ám | 10 Áin | Female | Board Edge Straddle Mount | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | Cantilever | 8 | Green | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Non Specified - Dual Edge | Solder | Card Extender | Dual | 125 °C | -40 C | 16 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Gold | 0.25 Ám | 10 Áin | Female | Board Edge Straddle Mount | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | Cantilever | 8 | Green | 0.128 " | 3.25 mm | Non Specified - Dual Edge | Solder | Dual | 125 °C | -40 C | 16 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Gold | 0.25 Ám | 10 Áin | Female | Through Hole | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | Cantilever | 16 | Green | 4-40 Threaded Insert Top Mount Opening | Non Specified - Single Edge | Wire Wrap | Single | 125 °C | -40 C | 16 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | Female | Through Hole | 1 | 1 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | Cantilever | 16 | Green | 0.128 " | 3.25 mm | Non Specified - Single Edge | Solder | Single | 125 °C | -40 C | 16 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | Female | Through Hole | 1 | 1 | ||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | Cantilever | 8 | Green | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Non Specified - Dual Edge | Solder | Dual | 125 °C | -40 C | 16 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Gold | 0.25 Ám | 10 Áin | Female | Through Hole | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | Cantilever | 16 | Green | 0.156 " | 3.96 mm | Non Specified - Single Edge | Wire Wrap | Single | 125 °C | -40 C | 16 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | Female | Through Hole | 1 | 1 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | Cantilever | 16 | Green | 4-40 Threaded Insert Top Mount Opening | Non Specified - Single Edge | Solder | Single | 125 °C | -40 C | 16 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | Female | Right Angle Through Hole | 1 | 1 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | Cantilever | 16 | Green | Non Specified - Single Edge | Solder | Single | 125 °C | -40 C | 16 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 0.25 Ám | 10 Áin | Female | Through Hole | 1 | 1 | ||||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 3.96 mm | 0.156 in | Cantilever | 8 | Green | 0.156 " | 3.96 mm | Non Specified - Dual Edge | Solder | Card Extender | Dual | 125 °C | -40 C | 16 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Gold | 0.25 Ám | 10 Áin | Female | Board Edge Straddle Mount |
