5973032 Series
Manufacturer: DIALIGHT
Beta
⌘K
LED RED CLEAR 1208 SMD
| Part | Color | Wavelength - Dominant | Lens Style | Configuration | Lens Transparency | Supplier Device Package | Lens Color | Lens Size [y] | Lens Size [x] | Viewing Angle | Current - Test | Millicandela Rating | Package / Case | Size / Dimension [x] | Size / Dimension [y] | Mounting Type | Wavelength - Peak | Voltage - Forward (Vf) (Typ) | Height (Max) [Max] [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 DIALIGHT | Red | 620 nm | Rectangle with Flat Top | Standard | Clear | 1208 | Colorless | 1.6 mm | 2.3 mm | 110 ° | 20 mA | 100 mcd | 1208 (3020 Metric) | 3 mm | 2 mm | Surface Mount | 620 nm | 2.2 V | 1.3 mm |
 DIALIGHT | Red | 620 nm | Rectangle with Flat Top | Standard | Clear | 1208 | Colorless | 1.6 mm | 2.3 mm | 110 ° | 20 mA | 100 mcd | 1208 (3020 Metric) | 3 mm | 2 mm | Surface Mount | 620 nm | 2.2 V | 1.3 mm |
