M2018ES Series
Manufacturer: NKK Switches
Beta
⌘K
SWITCH TOGGLE SPDT 0.4VA 28V
| Part | Electrical Life | Actuator Material | Mounting Type | Features | Operating Temperature [Max] | Operating Temperature [Min] | Bushing Thread | Illumination | Termination Style | Actuator Type | Voltage Rating - AC | Circuit | Actuator Length [x] | Switch Function | Current Rating (Amps) | Voltage Rating - DC | Panel Cutout Dimensions [diameter] | Bushing Thread |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NKK Switches | 50000 Cycles | Brass Chrome Plated | Panel Mount Right Angle Vertical | Epoxy Sealed Terminals | 85 °C | -30 ░C | 1/4-40 | Non-Illuminated | PC Pin | Flatted | 28 V | SPDT | 11.4 mm | Mom-Off-Mom | 0.4 VA | 28 V | 6.5 mm | |
 NKK Switches | 25000 Steps | Brass Chrome Plated | Through Hole | Epoxy Sealed Terminals | 85 °C | -30 ░C | Unthreaded | Non-Illuminated | PC Pin | Flatted | 125 V | SPDT | 11.4 mm | Mom-Off-Mom | 3 A 6 A | 30 V | 6.5 mm | |
 NKK Switches | 25000 Steps | Brass Chrome Plated | Panel Mount Right Angle Vertical | Epoxy Sealed Terminals | 85 °C | -30 ░C | 1/4-40 | Non-Illuminated | PC Pin | Flatted | 125 V | SPDT | 11.4 mm | Mom-Off-Mom | 3 A 6 A | 30 V | 6.5 mm | |
 NKK Switches | 25000 Steps | Brass Chrome Plated | Panel Mount | Epoxy Sealed Terminals | 85 °C | -30 ░C | 1/4-40 | Non-Illuminated | PC Pin | Flatted | 125 V | SPDT | 11.4 mm | Mom-Off-Mom | 3 A 6 A | 30 V | 6.5 mm | |
 NKK Switches | 25000 Steps | Brass Chrome Plated | Panel Mount | Epoxy Sealed Terminals | 85 °C | -30 ░C | 1/4-40 | Non-Illuminated | Wire Wrap | Flatted | 125 V | SPDT | 11.4 mm | Mom-Off-Mom | 3 A 6 A | 30 V | 6.5 mm | |
 NKK Switches | 50000 Cycles | Brass Chrome Plated | Through Hole | Epoxy Sealed Terminals | 85 °C | -30 ░C | Unthreaded | Non-Illuminated | PC Pin | Flatted | 28 V | SPDT | 11.4 mm | Mom-Off-Mom | 0.4 VA | 28 V | 6.5 mm | |
 NKK Switches | 50000 Cycles | Brass Chrome Plated | Right Angle Through Hole | Epoxy Sealed Terminals | 85 °C | -30 ░C | 1/4-40 | Non-Illuminated | PC Pin | Flatted | 28 V | SPDT | 11.4 mm | Mom-Off-Mom | 0.4 VA | 28 V | 6.5 mm | |
 NKK Switches | 50000 Cycles | Brass | Panel Mount | Dull Finish Actuator | 85 °C | -30 ░C | 1/4-40 | Non-Illuminated | Solder Lug | Flatted | 28 V | SPDT | 11.4 mm | Mom-Off-Mom | 0.4 VA | 28 V | 6.5 mm | |
 NKK Switches | 25000 Steps | Brass Chrome Plated | Panel Mount | Epoxy Sealed Terminals | 85 °C | -30 ░C | M6 | Non-Illuminated | Solder Lug | Flatted | 125 V | SPDT | 11.4 mm | Mom-Off-Mom | 3 A 6 A | 30 V | 6.5 mm | 0.75 |
 NKK Switches | 50000 Cycles | Brass Chrome Plated | Panel Mount | Epoxy Sealed Terminals | 85 °C | -30 ░C | 1/4-40 | Non-Illuminated | PC Pin | Flatted | 28 V | SPDT | 11.4 mm | Mom-Off-Mom | 0.4 VA | 28 V | 6.5 mm |
