A1123 Series
Manufacturer: Sunon Fans
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
FAN AXIAL 119.5X38.5MM 115VAC
| Part | Operating Temperature (Max) | Operating Temperature (Min) | Weight | Termination Count | Termination | Width | Bearing Type | Approval Agency | Air Flow | Size / Dimension Height | Size / Dimension Shape | Size / Dimension Length | Static Pressure | RPM | Voltage - Rated | Noise | Fan Type | Power (Watts) | Voltage Range (Min) | Voltage Range (Max) | Material - Blade | Current Rating | Material - Frame | Termination Leads Count | Termination Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sunon Fans | 158 °F | 14 °F | 1.2 lbs | 2 | 2 Terminals | 38.5 mm | Ball | CE cUR TUV UL | 117 CFM | 119.5 mm | Square | 119.5 mm | 0.39 in H2O | 3100 RPM | 115 V | 50 dB | Tubeaxial | 20 W | 75 VAC | 125 VAC | PBT Polybutylene Terephthalate | 0.25 A | Aluminum | ||
 Sunon Fans | 158 °F | 14 °F | 1.2 lbs | 2 Wire Leads | 38.5 mm | Sleeve | CE cUR TUV UL | 115 CFM | 119.5 mm | Square | 119.5 mm | 0.38 in H2O | 3100 RPM | 115 V | 49 dB | Tubeaxial | 20 W | 75 VAC | 125 VAC | PBT Polybutylene Terephthalate | 0.21 A | Aluminum | 2 leads | Wire Leads |
