SM312 Series
Manufacturer: BANNER ENGINEERING
Beta
⌘K
PHOTOELECTRIC SENSOR, MINI BEAM®, SM312 SERIES, DIVERGENT DIFFUSE, 130 MM, 10 VDC TO 30 VDC
| Part | Ingress Protection | Light Source | Output Configuration | Operating Temperature [Min] | Operating Temperature [Max] | Response Time | Sensing Method | Voltage - Supply [Min] | Voltage - Supply [Max] | Connection Method | Adjustment Type | Sensing Distance | Sensing Distance | Cable Length | Cable Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BANNER ENGINEERING | 12 2 3 3S 4 4X 6 IEC IEC IP67 IP67 NEMA 1 NEMA 12 NEMA 2 NEMA 3 NEMA 3S NEMA 4 NEMA 4X NEMA 6 | Infrared LED | Dark-ON/Light-ON NPN/PNP | -20 ░C | 70 °C | 1 ms | Diffuse | 10 VDC | 30 VDC | Connector | Adjustable Potentiometer | 5.118 in | 130 mm | ||
 BANNER ENGINEERING | 12 2 3 3S 4 4X 6 IEC IEC IP67 IP67 NEMA 1 NEMA 12 NEMA 2 NEMA 3 NEMA 3S NEMA 4 NEMA 4X NEMA 6 | Infrared LED | Dark-ON/Light-ON NPN/PNP | -20 ░C | 70 °C | 1 ms | Diffuse | 10 VDC | 30 VDC | Connector | Adjustable Potentiometer | 14.961 in | 380 mm | ||
 BANNER ENGINEERING | 12 2 3 3S 4 4X 6 IEC IEC IP67 IP67 NEMA 1 NEMA 12 NEMA 2 NEMA 3 NEMA 3S NEMA 4 NEMA 4X NEMA 6 | LED | NPN PNP | -20 ░C | 70 °C | 1 ms | Fiber Optic | 10 VDC | 30 VDC | Cable | Adjustable Potentiometer | 78.74 " | 2 m | ||
 BANNER ENGINEERING | 12 2 3 3S 4 4X 6 IEC IEC IP67 IP67 NEMA 1 NEMA 12 NEMA 2 NEMA 3 NEMA 3S NEMA 4 NEMA 4X NEMA 6 | LED | NPN PNP | -20 ░C | 70 °C | 1 ms | Fiber Optic | 10 VDC | 30 VDC | Connector | Adjustable Potentiometer | ||||
 BANNER ENGINEERING | 12 2 3 3S 4 4X 6 IEC IEC IP67 IP67 NEMA 1 NEMA 12 NEMA 2 NEMA 3 NEMA 3S NEMA 4 NEMA 4X NEMA 6 | Red LED | Dark-ON/Light-ON NPN/PNP | -20 ░C | 70 °C | 1 ms | Convergent | 10 VDC | 30 VDC | Connector | Adjustable Potentiometer | 1.693 in | 43 mm | ||
 BANNER ENGINEERING | 12 2 3 3S 4 4X 6 IEC IP67 NEMA 1 NEMA 1 2 3 3S 4 4X 6 12 IEC IP67 | RED (650nm) | Dark-ON/Light-ON NPN/PNP | -20 ░C | 70 °C | 1 ms | Convergent | 10 VDC | 30 VDC | Cable | Adjustable Potentiometer | 0.63 in | 16 mm | 78.74 " | 2 m |
BANNER ENGINEERING | 12 2 3 3S 4 4X 6 IEC IP67 NEMA 1 NEMA 1 2 3 3S 4 4X 6 12 IEC IP67 | RED (650nm) | Dark-ON/Light-ON NPN/PNP | -20 ░C | 70 °C | 1 ms | Retroreflective NonPolarized | 10 VDC | 30 VDC | Connector | Adjustable Potentiometer | 5 m 196.85 in | |||
 BANNER ENGINEERING | 12 2 3 3S 4 4X 6 IEC IEC IP67 IP67 NEMA 1 NEMA 12 NEMA 2 NEMA 3 NEMA 3S NEMA 4 NEMA 4X NEMA 6 | Red LED | Dark-ON/Light-ON NPN/PNP | -20 ░C | 70 °C | 1 ms | Retroreflective NonPolarized | 10 VDC | 30 VDC | Cable | Adjustable Potentiometer | 5 m 196.85 in | 78.74 " | 2 m | |
BANNER ENGINEERING | 12 2 3 3S 4 4X 6 IEC IP67 NEMA 1 NEMA 1 2 3 3S 4 4X 6 12 IEC IP67 | RED (650nm) | Dark-ON/Light-ON NPN/PNP | -20 ░C | 70 °C | 0.3 ms | Retroreflective NonPolarized | 10 VDC | 30 VDC | Cable | Adjustable Potentiometer | 5 m 196.85 in | 78.74 " | 2 m | |
 BANNER ENGINEERING | 12 13 2 3 3S 4 4X 6 IEC IP67 NEMA 1 | RED (650nm) | NPN/PNP - Dark-ON/Light-ON - Selectable | -20 ░C | 70 °C | 0.3 ms | Retroreflective NonPolarized | 10 VDC | 30 VDC | Adjustable Potentiometer | 5 m 196.85 in |
