ADS5271 Series
Manufacturer: Texas Instruments
Beta
⌘K
EIGHT-CHANNEL, 12-BIT, 50-MSPS ANALOG-TO-DIGITAL CONVERTER (ADC)
| Part | Configuration | Features | Number of A/D Converters | Mounting Type | Architecture | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Supply, Digital [Max] | Voltage - Supply, Digital [Min] | Ratio - S/H:ADC | Sampling Rate (Per Second) | Voltage - Supply, Analog [Max] | Voltage - Supply, Analog [Min] | Reference Type | Package / Case | Number of Bits | Supplier Device Package | Data Interface | Input Type | Number of Inputs | Input Range | Supplied Contents | Power (Typ) @ Conditions | Utilized IC / Part |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Texas Instruments | S/H-ADC | Simultaneous Sampling | 8 | Surface Mount | Pipelined | 85 °C | -40 °C | 3.6 V | 3 V | 1:1 | 50 M | 3.6 V | 3 V | External Internal | 80-TQFP Exposed Pad | 12 bits | 80-HTQFP (12x12) | LVDS - Serial | Differential | 8 | ||||
 Texas Instruments | S/H-ADC | Simultaneous Sampling | 8 | Surface Mount | Pipelined | 85 °C | -40 °C | 3.6 V | 3 V | 1:1 | 50 M | 3.6 V | 3 V | External Internal | 80-TQFP Exposed Pad | 12 bits | 80-HTQFP (12x12) | LVDS - Serial | Differential | 8 | ||||
 Texas Instruments | 8 | 50 M | 12 bits | Serial | 2.2 Vpp | Board(s) Cable(s) | 972 mW | ADS5271 |
