S602TS1 Series

Sen SCR 600V 1.5A 100 µA SOT223

Catalog

Sen SCR 600V 1.5A 100 µA SOT223

Part	Supplier Device Package	Voltage - On State (Vtm) (Max) [Max]	Current - Non Rep. Surge 50, 60Hz (Itsm)	Voltage - Off State	Mounting Type	SCR Type	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Current - Gate Trigger (Igt) (Max) [Max]	Current - On State (It (RMS)) (Max)	Current - Hold (Ih) (Max) [Max]	Current - Off State (Max) [Max] [custom]	Current - On State (It (AV)) (Max)	Voltage - Gate Trigger (Vgt) (Max)
LITTELFUSE S602TS1RP	SOT-223	1.7 V	12.5 A 15 A	600 V	Surface Mount	Sensitive Gate	TO-261-4 TO-261AA	-40 C	125 °C	100 µA	1.5 A	3 mA	5 µA	950 mA	800 mV

Catalog

Sen SCR 600V 1.5A 100 µA SOT223

Description

New 1.5Amp sensitive gate SCR series offers high static dv/dt with low turn off time (tq) through small die planar construction design. All SCR™ junctions are glass — passivated to ensure long term reliability and parametric stability.
