IMB08 Series

Catalog

SENSOR PROX INDUCTIVE 2MM CYL 2M

Part	Material - Body	Shielding	Operating Temperature [Min]	Operating Temperature [Max]	Ingress Protection	Sensor Type	Package / Case	Sensing Distance	Sensing Distance	Output Type	Indicator	Response Frequency	Voltage - Supply [Min]	Voltage - Supply [Max]	Termination Style	Output Type
SICK, Inc. 1072686	Plastic	Shielded	-40 °C	100 °C	IP68 IP69K	Inductive	Cylinder Threaded - M8	2 mm	0.079 in	3-Wire NPN-NC	No Indicator	4 kHz	10 VDC	30 VDC	Cable Leads
SICK, Inc. 1075585	Plastic	Shielded	-40 °C	100 °C	IP68 IP69K	Inductive	Cylinder Threaded - M8	2 mm	0.079 in	2-Wire NO	No Indicator	4 kHz	10 VDC	30 VDC	Cable Leads
SICK, Inc. 1072591	Plastic	Shielded	-40 °C	100 °C	IP68 IP69K	Inductive	Cylinder Threaded - M8	2 mm	0.079 in	3-Wire NPN-NC	No Indicator	4 kHz	10 VDC	30 VDC	Connector
SICK, Inc. 1072693	Plastic	Shielded	-40 °C	100 °C	IP68 IP69K	Inductive	Cylinder Threaded - M8	2 mm	0.079 in	3-Wire NPN-NC	No Indicator	4 kHz	10 VDC	30 VDC	Connector
SICK, Inc. 1072703	Plastic	Shielded	-40 °C	100 °C	IP68 IP69K	Inductive	Cylinder Threaded - M8	4 mm	0.157 in	3-Wire NPN-NC	No Indicator	4 kHz	10 VDC	30 VDC	Cable Leads
SICK, Inc. 1072685	Plastic	Shielded	-40 °C	100 °C	IP68 IP69K	Inductive	Cylinder Threaded - M8	2 mm	0.079 in	3-Wire NPN-NO	No Indicator	4 kHz	10 VDC	30 VDC	Cable Leads
SICK, Inc. 1072673	Stainless Steel	Unshielded	-40 C	100 °C	IP69K	Inductive	Cylinder Threaded - M8	2 mm	0.079 in	PNP-NO	LED	4 kHz	10 VDC	30 VDC	Connector	3
SICK, Inc. 1072589	Plastic	Shielded	-40 °C	100 °C	IP68 IP69K	Inductive	Cylinder Threaded - M8	2 mm	0.079 in	PNP-NC	No Indicator	4 kHz	10 VDC	30 VDC	Connector	3
SICK, Inc. 1072678	Plastic	Shielded	-40 °C	100 °C	IP68 IP69K	Inductive	Cylinder Threaded - M8	4 mm	0.157 in	PNP-NC	No Indicator	4 kHz	10 VDC	30 VDC	Connector	3
SICK, Inc. 1074352	Plastic	Shielded	-40 °C	100 °C	IP68 IP69K	Inductive	Cylinder Threaded - M8	2 mm	0.079 in	4-Wire NPN-NC/NO	LED	4 kHz	10 VDC	30 VDC	Connector
