BD9325FJ Series

4.75-18V 2A 1ch Buck converter

Catalog

4.75-18V 2A 1ch Buck converter

Part	Topology	Voltage - Input (Min) [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Package / Case [y]	Package / Case [x]	Voltage - Output (Max) [Max]	Output Type	Function	Current - Output	Voltage - Output (Min/Fixed)	Synchronous Rectifier	Supplier Device Package	Output Configuration	Frequency - Switching	Mounting Type	Number of Outputs	Voltage - Input (Max) [Max]
Rohm Semiconductor BD9325FJ-E2	Buck	4.75 V	85 °C	-40 °C	8-SOIC	3.9 mm	0.154 in	16.2 V	Adjustable	Step-Down	2 A	0.9 V		8-SOP-J	Positive	380 kHz	Surface Mount	1	18 V

Catalog

4.75-18V 2A 1ch Buck converter

Description

The BD9325FJ is step-down regulators that integrate a low resistance high side N-channel MOSFET. It achieves 2A continuous output current over a wide input supply range. Current mode operation provides fast transient response and easy phase compensation.
