807-068 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 68POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Gender | Mounting Type | Number of Rows [custom] | Flange Feature | Termination | Pitch | Pitch | Read Out | Color | Contact Type | Card Type | Number of Positions/Bay/Row | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Number of Positions | Flange Feature [diameter] | Flange Feature [diameter] | Features | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | Female | Right Angle Through Hole | 2 | Flush Mount M3 Threaded Insert Top Opening | Solder | 3.96 mm | 0.156 in | Single | Green | Semi Bellows | Non Specified - Dual Edge | 34 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | 68 positions | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | Female | Board Edge Straddle Mount | 2 | Side Mount Opening Unthreaded | Solder | 3.96 mm | 0.156 in | Dual | Green | Semi Bellows | Non Specified - Dual Edge | 34 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | 68 positions | 0.128 " | 3.25 mm | Card Extender | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | Female | Through Hole | 2 | Flush Mount Top Opening Unthreaded | Solder | 3.96 mm | 0.156 in | Dual | Green | Semi Bellows | Non Specified - Dual Edge | 34 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 68 positions | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | Female | Through Hole | 2 | Floating Bobbin Flush Mount | Solder | 3.96 mm | 0.156 in | Dual | Green | Semi Bellows | Non Specified - Dual Edge | 34 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | 68 positions | 0.116 " | 2.95 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | Female | Right Angle Through Hole | 2 | Side Mount Opening Unthreaded | Solder | 3.96 mm | 0.156 in | Single | Green | Semi Bellows | Non Specified - Dual Edge | 34 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 68 positions | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | Female | Through Hole | 2 | Flush Mount Top Opening Unthreaded | Solder Eyelet(s) | 3.96 mm | 0.156 in | Dual | Green | Semi Bellows | Non Specified - Dual Edge | 34 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | 68 positions | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | Female | Board Edge Straddle Mount | 2 | Flush Mount M3 Threaded Insert Top Opening | Solder | 3.96 mm | 0.156 in | Dual | Green | Semi Bellows | Non Specified - Dual Edge | 34 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | 68 positions | Card Extender | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | Female | Board Edge Straddle Mount | 2 | Solder | 3.96 mm | 0.156 in | Dual | Green | Semi Bellows | Non Specified - Dual Edge | 34 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | 68 positions | Card Extender | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | Female | Through Hole | 2 | 4-40 Flush Mount Threaded Insert Top Opening | Solder | 3.96 mm | 0.156 in | Dual | Green | Semi Bellows | Non Specified - Dual Edge | 34 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | 68 positions | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 125 °C | -40 C | Female | Through Hole | 2 | Side Mount Opening Unthreaded | Solder | 3.96 mm | 0.156 in | Dual | Green | Semi Bellows | Non Specified - Dual Edge | 34 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | 68 positions | 0.128 " | 3.25 mm |
