D09S91 Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
CONN D-SUB RCPT 9POS VERT PRESS
| Part | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Dielectric Material | Material Flammability Rating | Contact Type | Connector Type | Number of Positions | Color | Current Rating (Amps) | Connector Style | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Number of Rows | Contact Material | Termination | Flange Feature | Voltage Rating | Features | Contact Finish Thickness | Shell Material, Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Amphenol ICC (FCI) | 50 µin | 1.27 µm | Gold | Polybutylene Terephthalate (PBT) | UL94 V-0 | Signal | Receptacle Female Sockets | 9 | Black | 5 A | D-Sub | DE E | 1 | -55 °C | 125 °C | Through Hole | 2 | Phosphor Bronze | Press-Fit | Female Screwlock (4-40) Mating Side | 300 VDC | |||
Amphenol ICC (FCI) | 30 Áin | 0.76 Ám | Gold | Polybutylene Terephthalate (PBT) | UL94 V-0 | Signal | Receptacle Female Sockets | 9 | Black | 5 A | D-Sub | DE E | 1 | -55 °C | 125 °C | Through Hole | 2 | Phosphor Bronze | Press-Fit | Female Screwlock (M3) Mating Side | 300 VDC | Board Guide | ||
Amphenol ICC (FCI) | 30 Áin | 0.76 Ám | Gold | Polybutylene Terephthalate (PBT) | UL94 V-0 | Signal | Receptacle Female Sockets | 9 | Black | 5 A | D-Sub | DE E | 1 | -55 °C | 125 °C | Through Hole | 2 | Phosphor Bronze | Press-Fit | Female Screwlock (4-40) Mating Side | 300 VDC | Shielded | ||
Amphenol ICC (FCI) | 30 Áin | 0.76 Ám | Gold | Polybutylene Terephthalate (PBT) | UL94 V-0 | Signal | Receptacle Female Sockets | 9 | Black | 5 A | D-Sub | DE E | 1 | -55 °C | 125 °C | Through Hole | 2 | Phosphor Bronze | Press-Fit | Female Screwlock (4-40) Mating Side | 300 VDC | |||
Amphenol ICC (FCI) | Gold | Polybutylene Terephthalate (PBT) | UL94 V-0 | Signal | Receptacle Female Sockets | 9 | Black | 5 A | D-Sub | DE E | 1 | -55 °C | 125 °C | Through Hole | 2 | Phosphor Bronze | Press-Fit | Housing/Shell (4-40) | 300 VDC | Flash | Steel Tin-Nickel Plated | |||
 Amphenol ICC (FCI) | 30 Áin | 0.76 Ám | Gold | Polybutylene Terephthalate (PBT) | UL94 V-0 | Signal | Receptacle Female Sockets | 9 | Black | 5 A | D-Sub | DE E | 1 | -55 °C | 125 °C | Through Hole | 2 | Phosphor Bronze | Press-Fit | Housing/Shell (4-40) | 300 VDC | Steel Tin-Nickel Plated | ||
Amphenol ICC (FCI) | 30 Áin | 0.76 Ám | Gold | Polybutylene Terephthalate (PBT) | UL94 V-0 | Signal | Receptacle Female Sockets | 9 | Black | 5 A | D-Sub | DE E | 1 | -55 °C | 125 °C | Through Hole | 2 | Phosphor Bronze | Press-Fit | Housing/Shell (4-40) | 300 VDC | Steel Tin-Nickel Plated | ||
Amphenol ICC (FCI) | Gold | Polybutylene Terephthalate (PBT) | UL94 V-0 | Signal | Receptacle Female Sockets | 9 | Black | 5 A | D-Sub | DE E | 1 | -55 °C | 125 °C | Through Hole | 2 | Phosphor Bronze | Press-Fit | Female Screwlock (4-40) Mating Side | 300 VDC | Flash | Steel Tin-Nickel Plated | |||
Amphenol ICC (FCI) | Gold | Polybutylene Terephthalate (PBT) | UL94 V-0 | Signal | Receptacle Female Sockets | 9 | Black | 5 A | D-Sub | DE E | 1 | -55 °C | 125 °C | Through Hole | 2 | Phosphor Bronze | Press-Fit | Female Screwlock (M3) Mating Side | 300 VDC | Flash | Steel Tin-Nickel Plated | |||
Amphenol ICC (FCI) | Gold | Polybutylene Terephthalate (PBT) | UL94 V-0 | Signal | Receptacle Female Sockets | 9 | Black | 5 A | D-Sub | DE E | 1 | -55 °C | 125 °C | Through Hole | 2 | Phosphor Bronze | Press-Fit | Housing/Shell (M3) | 300 VDC | Flash |
